UNITROL 1005-0011 ECO 3BHE043576R0011励磁模块是一种功能强大的设备，用于控制和保护发电机的励磁系统，以确保电压和频率稳定，并提供灵活的编程和通信接口，以适应各种发电机应用。ABB UNITROL 1005-0011 ECO 3BHE043576R0011的参数和功能详情：参数：功率范围：UNITROL 1005励磁模块适用于各种发电机，功率范围通常为500 kVA至200 MVA。输入电压：励磁模块的输入电压通常为24 V DC或110 V DC，具体取决于应用需求。功能：励磁调节：UNITROL 1005励磁模块能够实现发电机的励磁调节，确保发电机输出的电压和频率在可接受的范围内。功率调节：励磁模块可以根据需求对发电机的输出功率进行调节，以满足电网负载的变化。励磁保护：该励磁模块提供各种励磁保护功能，如过电压保护、过电流保护、短路保护等，以保护励磁系统和发电机免受潜在故障的影响。
UNITROL-1005-0011
ABB推出了一款数字自动电压调节器(AVR)目标3.5MVA以下的同步机器。AVR是适用于同步电机并网使用单元或在孤岛操作中，几个单元并联连接。这种应用可以在海洋中找到工业以及在独立应用中使用变量速度如柴电机车，港口起重机柴油发电机组和船上装有直流电源的船舶网格。这种数字AVR是为要求苛刻的网格代码而设计的以及动态故障穿越要求(FRT)检测。对系统进行操作之前，请遵守以下安全预防措施:对系统进行操作之前，请遵守以下安全预防措施:断开所有可能的电压源连接。确保不能进行连接。上锁挂牌。打开AVR的主断开设备。对控制柜进行操作之前，断开任何外接电源与控制电路的连接。
UNITROL-1005-0011
通信接口：UNITROL 1005励磁模块配备了通信接口，可以与其他控制系统（如PLC或DCS）进行通信，实现系统集成和监控。自诊断和故障诊断：励磁模块具有自诊断功能，能够检测和报告系统中的故障，并提供相关的诊断信息，便于故障排除和维护。灵活性和可编程性：该励磁模块具有灵活的编程功能，可以根据特定的应用需求进行参数配置和定制。如果AVR连接永磁发电机，请使用安全开关或通过其他方式断开其与AVR的连接。·断开AVR连接后，请等待5分钟，使中间电路电容器得以放电，然后再继续操作。请保护工作地点中的其他任何带电部件，以免接触过电。靠近裸露的导体时，请采取特殊的预防措施。确保设备已断电。
UNITROL-1005-0011、
The UNITROL 1005-0011 ECO 3BHE043576R0011 excitation module is a powerful device used to control and protect the excitation system of generators, ensuring voltage and frequency stability, and providing flexible programming and communication interfaces to adapt to various generator applications. ABB UNITROL 1005-0011 ECO 3BHE043576R0011 parameters and functional details: Parameters: Power range: UNITROL 1005 excitation module is suitable for various generators, and the power range is usually 500 kVA to 200 MVA. Input voltage: The input voltage of the excitation module is usually 24 V DC or 110 V DC, depending on the application requirements. Function: Excitation regulation: The UNITROL 1005 excitation module can achieve excitation regulation of the generator, ensuring that the voltage and frequency output by the generator are within an acceptable range. Power regulation: The excitation module can adjust the output power of the generator according to demand to meet changes in grid load. Excitation protection: This excitation module provides various excitation protection functions, such as overvoltage protection, overcurrent protection, short circuit protection, etc., to protect the excitation system and generator from potential faults.
UNITROL-1005-0011
ABB has launched a synchronous machine with a digital automatic voltage regulator (AVR) target of less than 3.5MVA. AVR is suitable for grid connected units of synchronous motors or for parallel connection of several units in island operation. This application can be found in industries in the ocean and in independent applications using variable speeds such as diesel electric locomotives, port cranes, diesel generator sets, and ship grids equipped with DC power supplies. This digital AVR is designed for demanding grid code and dynamic fault traversal requirement (FRT) detection. Before operating the system, please follow the following safety precautions: Disconnect all possible voltage sources before operating the system. Ensure that connections cannot be made. Lock out and tag out. Turn on the main disconnect device of AVR. Before operating the control cabinet, disconnect any external power supply from the control circuit.
UNITROL-1005-0011
Communication interface: The UNITROL 1005 excitation module is equipped with a communication interface, which can communicate with other control systems (such as PLC or DCS) to achieve system integration and monitoring. Self diagnosis and fault diagnosis: The excitation module has self diagnosis function, which can detect and report faults in the system, and provide relevant diagnostic information for easy troubleshooting and maintenance. Flexibility and programmability: The excitation module has flexible programming functions, which can be configured and customized according to specific application requirements. If the AVR is connected to a permanent magnet generator, please use a safety switch or disconnect it from the AVR through other means· After disconnecting the AVR connection, please wait for 5 minutes for the intermediate circuit capacitor to discharge before continuing with the operation. Please protect any other live parts in the workplace from contact with electricity. Please take special precautions when approaching exposed conductors. Ensure that the device is powered off.
