UNITROL 1010是一个强大的小型间接励磁系统，内建支持双频道，用于并行运行机组中的先进的负载分配，旋转二极管监控，自动同步和多种一体化通信选项。UNITROL 1010是UNITROL 1000系列中设计用于中小型的同步发电机和工业机器的电压调节器。基于先进的微处理器技术和允许用于持续操作的电流输出高达10ADC的IGBT半导体器件。UNITROL 1010可在严苛条件和不同温度范围下进行高性能工作，并且完全符合DNV和UL标准。UNITROL 1010相较于之前的版本的额外特点是以太网,USB连接，数据和事件记录和许多新的功能。UNITROL 1010是为励磁电流最高10A的设备设计的小型化设备。和UNITROL 1020共用同样的界面和尺寸。
UNITROL-1010
发电机励磁系统是供给同步发电机励磁电流°的电源及其附属设备的统称。它一般由励磁功率单元和励磁调节器两个主要部分组成。发电机励磁系统包括直流励磁机、无刷励磁机-、交流励磁机等。近十多年来，由于新技术，新工艺和新器件的涌现和使用，使得发电机的励磁方式°得到了不断的发展和完善。在自动调节°励磁装置方面，也不断研制和推广使用了许多新型的调节装置。励磁功率单元向同步发电机转子°提供励磁电流;而励磁调节器°则根据输入信号°和给定的调节准则控制励磁功率单元的输出。励磁系统的自动励磁调节器°对提高电力系统并联机组的稳定性具有相当大的作用。尤其是现代电力系统°的发展导致机组稳定极限降低的趋势，也促使励磁技术Q不断发展。同步发电机的励磁系统主要由功率单元和调节器（装置）两大部分组成。
UNITROL-1010
UNITROL 1010 is a powerful small indirect excitation system with built-in support for dual channels, used for advanced load distribution, rotating diode monitoring, automatic synchronization, and multiple integrated communication options in parallel operating units. UNITROL 1010 is a voltage regulator designed for small and medium-sized synchronous generators and industrial machines in the UNITROL 1000 series. IGBT semiconductor devices based on advanced microprocessor technology and allowing for continuous operation with current output up to 10ADC. UNITROL 1010 can perform high-performance work under harsh conditions and different temperature ranges, and fully complies with DNV and UL standards. The additional features of UNITROL 1010 compared to previous versions are Ethernet, USB connectivity, data and event recording, and many new features. UNITROL 1010 is a miniaturized device designed for equipment with excitation currents up to 10A. Share the same interface and size as UNITROL 1020.
UNITROL-1010
The generator excitation system is a collective term for the power supply and its auxiliary equipment that supply the excitation current ° of synchronous generators. It generally consists of two main parts: an excitation power unit and an excitation regulator. The generator excitation system includes DC exciter, brushless exciter, AC exciter, etc. In the past decade, due to the emergence and use of new technologies, processes, and devices, the excitation method of generators has been continuously developed and improved. In terms of automatic regulation of excitation devices, many new types of regulation devices have also been continuously developed and promoted. The excitation power unit provides excitation current to the synchronous generator rotor °; The excitation regulator controls the output of the excitation power unit based on the input signal ° and the given regulation criteria. The automatic excitation regulator of the excitation system plays a significant role in improving the stability of parallel units in the power system. Especially with the development of modern power systems, the trend of reducing the stability limit of units has also led to the continuous development of excitation technology Q. The excitation system of a synchronous generator mainly consists of two parts: a power unit and a regulator (device).
UNITROL-1010
