触摸界面： 这款触摸面板具备触摸界面，用户可以通过触摸操作来与系统进行交互和控制。显示屏： 触摸面板通常配备液晶显示屏，用于显示控制界面、数据和信息。分辨率： 显示屏可能有特定的分辨率，以确保图像和界面的清晰度。多点触控： 一些触摸面板支持多点触控技术，允许用户同时使用多个手指进行操作。通信接口： 触摸面板可能通过不同的通信接口与其他设备或系统连接，如以太网、串口等。可编程性： 这类触摸面板可能具备可编程功能，用户可以自定义界面和控制逻辑。应用领域： 触摸面板广泛应用于工业自动化、机器控制、监视和人机界面等领域。耐用性： 工业环境通常要求设备具备耐用性，以适应恶劣的工作条件。
XV-440-10TVB-1-20
CAN/easyNet,Ul508,cUL批准，PLC功能可由用户安装，通信范围可由用户使用许可证安装，显示类型:彩色显示，TFT，触摸技术红外触摸，颜色数量:可调:65536或256色，分辨率:VGA，640 × 480操作系统:Windows CE，需要CompactFlash卡，PLC-许可证可由用户安装编号为140390的LIC-PLC-MXP-介质，板载接口的许可证证书:可根据需要扩展，请参见附件-%3E许可证产品证书，内置接口:1个以太网100base-TX/10base-T，1个RS232，1个Can，2个USB主机，1个USB设备，正面类型:标准正面，带标准薄膜，层压安全玻璃，不反光，用途:嵌入式安装,插槽;用于紧凑型存储卡自动化:必需，见附件-%3E存储卡，可插拔通信卡(可选):是，散热:32W，防护等级(EC/EN 60529，EN50178，VBG4);IP65(前面)，IP20(后面)。
XV-440-10TVB-1-20
Touch interface: This touch panel has a touch interface, allowing users to interact and control with the system through touch operations. Display screen: Touch panels are usually equipped with LCD screens for displaying control interfaces, data, and information. Resolution: The display screen may have a specific resolution to ensure clarity of the image and interface. Multi touch: Some touch panels support multi touch technology, allowing users to operate with multiple fingers simultaneously. Communication interface: The touch panel may be connected to other devices or systems through different communication interfaces, such as Ethernet, serial ports, etc. Programmability: This type of touch panel may have programmable functions, allowing users to customize the interface and control logic. Application field: Touch panels are widely used in industrial automation, machine control, monitoring, and human-machine interface fields. Durability: Industrial environments typically require equipment to have durability to adapt to harsh working conditions.
XV-440-10TVB-1-20
CAN/easyNet, Ul508, cUL approved, PLC function can be installed by the user, communication range can be installed by the user using a license, display type: color display, TFT, touch technology infrared touch, color quantity: adjustable: 65536 or 256 colors, resolution: VGA, 640 × 480 operating system: Windows CE, requires a CompactFlash card, PLC license can be installed by the user with LIC-PLC-MXP media number 140390, license certificate for onboard interface: can be expanded as needed, please refer to attachment -% 3E license product certificate, built-in interface: 1 Ethernet 100base-TX/10base-T, 1 RS232, 1 Can, 2 USB hosts, 1 USB device, front type: standard front, with standard film, laminated safety glass, non reflective, Purpose: Embedded installation, slot; For compact storage card automation: required, see attachment -% 3E storage card, pluggable communication card (optional): Yes, heat dissipation: 32W, protection level (EC/EN 60529, EN50178, VBG4); IP65 (front), IP20 (rear).
XV-440-10TVB-1-20
