873EC分析仪可测量水溶液的电导率。可以以pS/ cm， mS / cm或百分比(%）读取其测显显示。FOXBORO 873EC-JIPFGZ 电导率仪溶液温度也由873EC测量，用于自动温度补偿，并且可以在用户需要时显示。它提供与测量值成比例的隔离输出信号，以传输到外部接收器。安装在塑料面板上的分析仪仅发送一个输出信号，而金属外壳分析仪则可以发送两个输出信号。873EC分析仪测量水溶液的电导率。其测量显示可以以S/cm, mS/cm或百分比(%)读取。解决方案温度也由873EC测量，用于自动温度补偿,并可在用户需要时显示。
873EC-JIPFGZ
FOXBORO 873EC-JIPFGZ 电导率仪它提供与测量成比例的隔离输出信号,以传输到外部接收器。安装在塑料面板上的分析仪仅传输一个输出信号 ，而金属外壳分析仪可以传输两个输出信号。仪器功能以下描述了873EC电化学分析仪的一些功能:塑料或金属NEMA 4X外壳双重警报金属外壳上的双隔离模拟输出。EEPROM存储器危险区域分类(金属单位)前面板显示屏前面板键盘应用灵活性外慌塑料外壳适用于通用位置的面板安装，以吸1/4 DIN尺寸面板孔的安装 。
873EC-JIPFGZ
FOXBORO 873EC-JIPFGZ 电导率仪它符合NEMA 1, CSA Enclosure 1和IEC防护等级IP -45的外壳等级。金属外壳适用于现场位置，可以是面板，管道或表面安装。外情是挤压铝，涂有坚韧的环氧基涂料。外壳防水，防尘，耐腐蚀，符合NEMA 4X, CSA外壳4X和IEC防护等级IP -65的外壳等级。该装置适合92 x 92 mm (3.6×3.6 in)面板开孔(1/4 DIN尺寸)。现场安装的机箱可提供射频干扰(RFI) 和电磁干扰(EMI) 保护。
873EC-JIPFGZ
The 873EC analyzer can measure the conductivity of aqueous solutions. The measurement display can be read in pS/cm, mS/cm, or percentage (%). The solution temperature of the FOXBORO 873EC-JIPFGZ conductivity meter is also measured by 873EC for automatic temperature compensation and can be displayed when needed by the user. It provides an isolated output signal proportional to the measured value for transmission to an external receiver. The analyzer installed on a plastic panel can only send one output signal, while the metal case analyzer can send two output signals. The 873EC analyzer measures the conductivity of aqueous solutions. Its measurement display can be read in S/cm, mS/cm, or percentage (%). The solution temperature is also measured by 873EC for automatic temperature compensation and can be displayed when needed by the user.
873EC-JIPFGZ
The FOXBORO 873EC-JIPFGZ conductivity meter provides an isolated output signal proportional to the measurement for transmission to an external receiver. The analyzer installed on a plastic panel only transmits one output signal, while the metal case analyzer can transmit two output signals. The following describes some of the functions of the 873EC electrochemical analyzer: dual isolation analog output on the plastic or metal NEMA 4X enclosure with dual alarms on the metal enclosure. EEPROM memory hazardous area classification (metal units) Front panel display screen Front panel keyboard application flexibility Outer panic plastic shell suitable for panel installation in general positions, to absorb 1/4 DIN size panel holes for installation.
873EC-JIPFGZ
The FOXBORO 873EC-JIPFGZ conductivity meter complies with NEMA 1, CSA Enclosure 1, and IEC protection class IP-45 enclosure ratings. The metal casing is suitable for on-site locations and can be panel, pipeline, or surface mounted. The external situation is extruded aluminum, coated with a tough epoxy based coating. The housing is waterproof, dustproof, corrosion-resistant, and meets the housing ratings of NEMA 4X, CSA housing 4X, and IEC protection level IP-65. This device is suitable for panel openings (1/4 DIN size) of 92 x 92 mm (3.6×3.6 in). The on-site installed chassis can provide radio frequency interference (RFI) and electromagnetic interference (EMI) protection.
