1747-L552是SLC 500处理器，属于SLC 5/05的子类别。该处理器是一个单槽处理器，直接连接到任何SLC 500机箱的背板。该处理器集成了用于点对点通信的RS232端口和用于网络应用和同步数据交换的以太网通信。这款处理器非常适合用于大中型应用，重点是将机器级领域集成到企业级领域。该处理器还为工业物联网(lloT)需求提供了实用的集成特性。与SLC 500平台下的其他处理器不同，这些处理器的嵌入式通信能力包括DH485、Data Highway Plus (DH+)、远程I/O和DeviceNet。这些通信协议是专有的，需要专业模块或第三方转换器和网关来实现垂直集成。借助嵌入式以太网，这款处理器开箱即可用于垂直集成。
1747-L552
1747-L2552的大存储容量具有4096个输入和输出的IO容量，允讦处理器控制多个小进程或单个大进程。必须考虑系统关键茬度，以止确规划哪些流程可以包含在相同的处理器中。它还支持远程I/O拓扑实现，以允许I/O模块的战略性安装。该模块的最大用户内存为32K字，其中28K字用于数据或程序，4K字用于用户数据。对于输入和输出，处理器还有一个绝对最大数量的/O，每个都是4096。它也有一个480分的最高本地模拟。该处理器支持多达一百零七(107)条编程指令，并允许安装多达三(3)个机箱，最多三十(30)个插槽。该处理器的最大输入电流在5伏DC时为1A，在24伏DC时为0A。
1747-L552、
AB 1747-L552 处理器模块它的典型程序扫描时间为0.9毫秒/K，V/O扫描时间为0.225毫秒，XiC位执行时间为0.37秒。根据电源负载，该处理器在断电后的程序扫描保持时间为20毫秒至3秒。它的工作振动为0.015英寸，峰峰值位移为5至57赫兹，加速度为2.5G，频率为57至20O0赫兹。该处理器还具有30G的工作冲击和5%至95%的非冷凝相对湿度。该处理器的工作温度范围为0至60摄氏度，存储温度范围为-40至85摄氏度。
1747-L552
1747-L552 is an SLC 500 processor, belonging to the subcategory of SLC 5/05. This processor is a single slot processor that is directly connected to the backplane of any SLC 500 chassis. This processor integrates RS232 ports for peer-to-peer communication and Ethernet communication for network applications and synchronous data exchange. This processor is very suitable for large and medium-sized applications, with a focus on integrating machine level domains into enterprise level domains. This processor also provides practical integration features for industrial IoT requirements. Unlike other processors on the SLC 500 platform, their embedded communication capabilities include DH485, Data Highway Plus (DH+), remote I/O, and DeviceNet. These communication protocols are proprietary and require professional modules or third-party converters and gateways to achieve vertical integration. With embedded Ethernet, this processor can be used for vertical integration out of the box
1747-L552
The large storage capacity of 1747-L2552 has an IO capacity of 4096 inputs and outputs, allowing the processor to control multiple small processes or a single large process. It is necessary to consider system criticality to accurately plan which processes can be included in the same processor. It also supports remote I/O topology implementation to allow for strategic installation of I/O modules. The maximum user memory of this module is 32K words, of which 28K words are used for data or programs, and 4K words are used for user data. For input and output, the processor also has an absolute maximum number of/Os, each of which is 4096. It also has a maximum local simulation of 480 points. This processor supports up to one hundred and seven (107) programming instructions and allows for the installation of up to three (3) chassis, with a maximum of thirty (30) slots. The maximum input current of this processor is 1A at 5 V DC and 0A at 24 V DC.
1747-L552
The typical program scan time of the AB 1747-L552 processor module is 0.9 ms/K, the V/O scan time is 0.225 ms, and the XiC bit execution time is 0.37 seconds. According to the power load, the program scan hold time of the processor after power outage is 20 milliseconds to 3 seconds. Its working vibration is 0.015 inches, peak to peak displacement is 5 to 57 Hz, acceleration is 2.5G, and frequency is 57 to 20O0 Hz. The processor also has a working shock of 30G and a non condensing relative humidity of 5% to 95%. The operating temperature range of this processor is 0 to 60 degrees Celsius, and the storage temperature range is -40 to 85 degrees Celsius.
