Allen-Bradley 1756-L71S 是一款 GuardLogix 5570 控制器，是 Logix5000 系列控制器的一部分。它是一个具有安全功能的ControlLogix控制器。它是一种双处理器解决方案，必须与 1756-L7SP 安全模块配合使用，以满足 SIL 3 或 Cat 的要求。4/PLe 安全标准。安全合作伙伴控制器是自动配置的，为单个项目提供了主要优势。它具有强大的处理能力和运动速度以及高性能逻辑。它有一个用于通信的USB端口，最多可以支持500个控制器连接。1756-L71S 控制器具有 2MB 用户内存、1MB 安全内存和 0.98MB I/O 内存。它可以支持 128,000 个数字 I/O 和 4000 个模拟 I/O。它在 5.1V DC 时吸收 2mA 电流，在 800.5V DC 时吸收 1mA 电流。其功耗为2.5W，热耗散为8.5 BTU/hr。
1756-L71
它重 0.55 磅，具有 30V（连续）的隔离电压，用于基本绝缘。它可以安装在 ControlLogix 1756 机箱的任何插槽中。为了安全通信，它使用ControlNet，DeviceNet或EtherNet/IP网络。1756-L71S 控制器可以通过背板或通过 I/O 链路控制或监视 I/O。对于控制器诊断，它有一个提供运行时信息的前面板显示屏。它使用1756-ESMCAP和1756-ESMCAPK储能模块工作，这意味着不需要锂电池。1 GB （1784-SD1） 安全数字卡作为可选的非易失性存储预装，可扩展至 2 GB （1784-SD2）。
1756-L71
Allen Bradley 1756-L71S is a GuardLogix 5570 controller that is part of the Logix5000 series of controllers. It is a ControlLogix controller with security features. It is a dual processor solution that must be used in conjunction with the 1756-L7SP security module to meet the requirements of SIL 3 or Cat. 4/PLe safety standards. The security partner controller is automatically configured, providing the main advantage for individual projects. It has strong processing power, motion speed, and high-performance logic. It has a USB port for communication and can support up to 500 controller connections. The 1756-L71S controller has 2MB user memory, 1MB safe memory, and 0.98MB I/O memory. It can support 128000 digital I/Os and 4000 analog I/Os. It absorbs 2mA current at 5.1V DC and 1mA current at 800.5V DC. Its power consumption is 2.5W and thermal dissipation is 8.5 BTU/hr.
1756-L71
It weighs 0.55 pounds and has a continuous isolation voltage of 30V, used for basic insulation. It can be installed in any slot of the ControlLogix 1756 chassis. For secure communication, it uses ControlNet, DeviceNet, or EtherNet/IP networks. The 1756-L71S controller can control or monitor I/O through the backplane or through the I/O link. For controller diagnosis, it has a front panel display screen that provides runtime information. It operates using 1756-ESMCAP and 1756-ESMCAPK energy storage modules, which means there is no need for lithium batteries. A 1 GB (1784-SD1) secure digital card is pre installed as an optional nonvolatile storage and can scale up to 2 GB (1784-SD2).
1756-L71
