Kinetix 6000多轴驱动器2094-BM01-S是一个安讯士模块，可通过反馈电缆直接连接受控设备。该轴模块与集成轴模块、控制模块、分流模块和构成Kinetix Drive运动控制系统的其他基本组件一起安装在电源导轨上。Kinetix drive为用户提供了实现电机同步运动控制的能力，通常用于制造业的机器中。这种驱动系统提供了精确和同步的控制，使电机和兼容的运动设备作为一个单元。2094-BM01-S has是一个400VAC级Axis模块，A系列的持续电流为6.1 A，峰值电流为9.2A，B和C系列的驱动为15.3 A，持续输出功率为3.9 kW。其效率为98%，短路电流额定值为200，000 A (rms)对称。
2094-BM01-S
A-B 2094-BM01-S 安讯士模块它有一个集成的分流器，持续功率为50W，峰值功率为5.6 kW。模块的内部分流电阻器的电阻值为115欧姆。模块的工作温度要求为0…50°C(32…122°F ),相对湿度为5…95%,无冷凝。它也可以在海拔1000米(3281英尺)的高度运行而不降低性能，在海拔3000米(9843英尺)的高度运行而降低性能。模块可接受的振动范围为5…55赫兹@ 0.35毫米(0.014英寸)。)双振幅，连续位移；55…500 Hz @ 2.0 g峰值恒定加速度，冲击额定值为15 g，11 ms半正弦脉冲。
2094-BM01-S
The Kinetix 6000 multi axis drive 2094-BM01-S is an Axis module that can be directly connected to controlled devices through a feedback cable. The axis module is installed on the power rail along with the integrated axis module, control module, splitter module, and other basic components that make up the Kinetix Drive motion control system. Kinetex drive provides users with the ability to achieve synchronous motor motion control, typically used in manufacturing machines. This drive system provides precise and synchronous control, allowing the motor and compatible motion devices to be integrated as a unit. 2094-BM01-S has is a 400VAC level Axis module, with a continuous current of 6.1 A and a peak current of 9.2 A for the A series, 15.3 A for the B and C series drives, and a continuous output power of 3.9 kW. Its efficiency is 98%, and the short-circuit current rating is symmetrical at 200000 A (rms).
2094-BM01-S
The A-B 2094-BM01-S Axis module has an integrated splitter with a continuous power of 50W and a peak power of 5.6 kW. The resistance value of the internal shunt resistor of the module is 115 ohms. The operating temperature requirement of the module is 0… 50 ° C (32… 122 ° F), relative humidity is 5… 95%, and there is no condensation. It can also operate at an altitude of 1000 meters (3281 feet) without compromising performance, and at an altitude of 3000 meters (9843 feet) without compromising performance. The acceptable vibration range for the module is 5… 55 Hz @ 0.35 mm (0.014 inches) Dual amplitude, continuous displacement; 55… 500 Hz @ 2.0 g peak constant acceleration, with an impact rating of 15 g and a half sine pulse of 11 ms.
2094-BM01-S
