Allen-Bradley 2098-DSD-020 x-DN Ultra 3000数字伺服驱动模块是一种单相交流驱动器，用于控制大多数工业伺服电机。该模块带有DeviceNet和索引。2098-DSD-020X-DN的工作冲击为15g (3个脉冲，11毫秒)。该模块的非操作冲击为30 g (3个脉冲，11 ms)。该模块设计用于在2.5 g振动下保持最佳功能。该模块可在高达1000米(3280英尺)的海拔高度下运行，无需降额。该模块的工作温度为0 -55摄氏度(32-131华氏度)。该模块的储存温度为-40-70°C(-40-158°F)。该模块的相对湿度为5-95%，无冷凝。艾伦-布拉德利2098-DSD-020X-DN重2.1千克(4.6磅)。此模块的尺寸为7.8 x 5.68 x 3.89英寸(198.12 x 144.27 x 98.1毫米)。
2098-DSD-020X
Allen-Bradley 2098-DSD-020X-DN的输入电压(AC)为100-240V交流均方根(单相)。该模块的输入频率(AC)为47-63赫兹。该模块的标称输入电流(AC)为18 A均方根值。它还具有健康的10 A (0峰值)连续输出电流和30 A (0峰值)间歇输出电流。如果在电源打开时连接或断开2098-DSD-020X-DN模块，可能会产生电弧。这可能会在危险场所引起爆炸。重复的电动伸缩装置会导致模块及其配套连接器上的触点过度磨损。
2098-DSD-020X
The Allen Bradley 2098-DSD-020 x-DN Ultra 3000 digital servo drive module is a single-phase AC driver used to control most industrial servo motors. This module comes with DeviceNet and indexes. The working shock of 2098-DSD-020X-DN is 15g (3 pulses, 11 milliseconds). The non operational impact of this module is 30 g (3 pulses, 11 ms). This module is designed to maintain optimal functionality under 2.5 g vibration. This module can operate at altitudes up to 1000 meters (3280 feet) without derating. The operating temperature of this module is 0-55 degrees Celsius (32-131 degrees Fahrenheit). The storage temperature of this module is -40-70 ° C (-40-158 ° F). The relative humidity of this module is 5-95% and there is no condensation. Allen Bradley 2098-DSD-020X-DN weighs 2.1 kilograms (4.6 pounds). The dimensions of this module are 7.8 x 5.68 x 3.89 inches (198.12 x 144.27 x 98.1 mm)
2098-DSD-020X
The input voltage (AC) of Allen Bradley 2098-DSD-020X-DN is 100-240V AC root mean square (single-phase). The input frequency (AC) of this module is 47-63 Hz. The nominal input current (AC) of this module is 18 A root mean square value. It also has a healthy 10 A (0 peak) continuous output current and 30 A (0 peak) intermittent output current. If the 2098-DSD-020X-DN module is connected or disconnected while the power is turned on, an arc may occur. This may cause explosions in hazardous locations. Repeated electric telescopic devices can cause excessive wear on the contacts on the module and its mating connectors.
2098-DSD-020X
PLC控制器本身的硬件采用积木式结构，各厂家产品结构大同小异。以日本欧姆龙C200HE为例，为总线模板框式结构，基本框架(CPU母板)上装有CPU模板，其它槽位装有I/O模板;如果I/O模板多时，可由CPU母板经I/O扩展电缆连接I/O扩展母板，在其上装I/O模板;另一种方法是配备远程I/O从站等。这些都说明了PLC厂家将硬件各部件均向用户开发，便于用户选用，配置成规模不等的PLC，而且这种硬件配置的开放性，为制造商、分销商(代理商)、系统集成商、最终用户带来很多方便，为营销供应链带来很大便利，这是一大成功经验。
2098-DSD-020X
