Allen-Bradley 2711P-T10C4A9 PanelView Plus 6 终端具有扩展功能和文件查看器。它可以以图形方式显示应用程序状态信息，允许操作员控制和监视其他机器。2711P-T10C4A9具有灵活的配置过程，具有单独的显示模块和逻辑模块以及可选的通信模块。用户可以利用触摸屏输入信息和数据来控制操作员界面。2711P-T10C4A9 具有 10.4 英寸彩色显示屏，带有用于输入选项的电阻式触摸屏。触摸屏分辨率为 640 x 480，具有 18 位彩色图形。它具有512 MB的RAM和512 MB的非易失性存储器，用于用户存储。它重 8 磅，尺寸为 16 x 14 x 8 英寸。其输入电压为 100 至 240 伏交流电，50 至 60 赫兹，最大功耗为 160 VA。对于通信，它有一个以太网端口、一个 RS-232 端口和 2 个 USB 端口。2711P-T10C4A9 还可以支持可选的 DH-485、DH+、控制网和以太网模块。
2711P-T10C4A9
它带有电池备份的实时时钟，并支持用于外部存储的SD卡。2711P-T10C4A9在处理器速度、内存、照明和连接性方面比以前的 PanelView 终端有了显著改进。以太网端口使用网络和标准以太网连接连接到以太网/IP 网络上的控制器。此端口可以处理应用程序传输并处理打印。EtherNet/IP 屏幕允许用户修改 PanelView 终端的一些 EtherNet/IP 通信设置。如果需要另一个以太网端口，2711P-RN20 以太网通信模块可用于 700 至 1500 终端。该模块具有自己唯一的 IP 地址。此端口具有用于网络通信的 RJ45、10/100Base-T 连接器，并支持 MDI/MDI-X 连接。
2711P-T10C4A9
The Allen Bradley 2711P-T10C4A9 PanelView Plus 6 terminal has extended functionality and file viewers. It can display application status information in a graphical manner, allowing operators to control and monitor other machines. The 2711P-T10C4A9 has a flexible configuration process, with separate display and logic modules, as well as optional communication modules. Users can use the touch screen to input information and data to control the operator interface. The 2711P-T10C4A9 features a 10.4-inch color display screen with a resistive touch screen for input options. The touch screen resolution is 640 x 480, with 18 bit color graphics. It has 512 MB of RAM and 512 MB of non volatile memory for user storage. It weighs 8 pounds and measures 16 x 14 x 8 inches. Its input voltage is 100 to 240 VAC, 50 to 60 Hz, and the maximum power consumption is 160 VA. For communication, it has one Ethernet port, one RS-232 port, and two USB ports. The 2711P-T10C4A9 can also support optional DH-485, DH+, control network, and Ethernet modules.
2711P-T10C4A9
It comes with a battery backed real-time clock and supports SD cards for external storage. 2711P-T10C4A9 has made significant improvements in processor speed, memory, lighting, and connectivity compared to previous PanelView terminals. Ethernet ports connect to controllers on Ethernet/IP networks using network and standard Ethernet connections. This port can handle application transfers and printing. The EtherNet/IP screen allows users to modify some EtherNet/IP communication settings on the PanelView terminal. If another Ethernet port is required, the 2711P-RN20 Ethernet communication module can be used for 700 to 1500 terminals. This module has its own unique IP address. This port has RJ45, 10/100Base-T connectors for network communication, and supports MDI/MDI-X connections.
