通道继电器模块是一个全高模块，提供16个继电器输出。任意数量的16通道继电器模块可以放置在任何机柜接口模块右侧槽位。每个输出16通道继电器模块可以独立编程执行所需的投票逻辑。在16通道继电器模块上使用的每个继电器都包括”报警驱动逻辑”。编程的报警驱动器逻辑采用与或逻辑,并可使用报警输入警报和危险状态,不OK,或来自个别ppl机架中的任何监视器通道或监视器通道的任何组合。驴使用3500机架配置软件编程此告警驱动器来满足应用程序的特定需求。3500台监视器按倍数订购批准选项被认证为区域2标准包括ATEX和北美区。Zone 2标准指定增加在较高电压下的间距要求3500/33继电器不符合这些间距要求。因此，3500/33继电器使用多个批准选项订购历史上是否被限制在一个较低的水平电压比 与另-种排列的电压高批准的选择。使用更高的电压违反危险区域证书与多个批准选项关联。
3500-33
北美2区标准与CSA-only approvals选项相关联已降至30Vrms以配合符合61010-1型试验要求。如果3500/33是功能安全的一部分(SIL)系统，功能安全证书需要限制电压。更高的电压不允许使用功能安全(SIL)系统。可以将现场接线连接到3500/33继电器这样的导体暴露于潜在的人类接触。这可能在高压下有触电危险。客户应只使用3500/33继电器电压高达30Vrms。适当的安全应采取预防措施电击的危险。16通道继电器模块是一 个全高模块，它提供16个继电器输出。你可以放置任意数量的16-右侧任何插槽中的通道继电器模块瞬态数据接口模块。16通道继电器模块的每个输出可以是独立编程以执行表决逻辑。模块的每个继电器都包括报警驱动逻辑。报警驱动逻辑的编程使用AND和or逻辑and可以使用以下内容:n报警输入警报和危险状态不太好来自任何监控通道的n个单独的测量变量或者机架中监视器通道的任意组合您可以使用3500框架对报警驱动进行编程配置软件。n 16通道继电器模块需要3500框架配置，版本3.3或更高版本。
3500-33
16通道继电器模块需要3500数据采集软件, 2.40或更高版本。16通道继电器模块需要3500数据显示软件，版本=1.40或更高。 n以倍数订购时认证选项，3500显示器是通过2区标准认证，包括ATEX和北美地区。n 2区标准规定增加更电压下的间距要求。16通道继电器模块不满足这些间距要求。因此，与倍数- 起订购的模块批准选项仅限于较低的电压比那些与其他批准选项。n使用更高的电压违反了与以下相关的危险区域证书多重批准选项。北美第2部分标准与仅限CSA的批准相关联选项已降级为30Vrms符合61010-1型式试验要求。 n如果1 6通道继电器模块是功能安全(SIL)系统功能安全证书要求受限电压。更高的电压不会允许用于功能安全(SIL)系统。
3500-33
The channel relay module is a full height module that provides 16 relay outputs. Any number of 16 channel relay modules can be placed in the right slot of any cabinet interface module. Each output 16 channel relay module can be independently programmed to execute the required voting logic. Each relay used on the 16 channel relay module includes “alarm drive logic”. The programmed alarm driver logic adopts AND or logic and can use alarm inputs for alarm and danger states, not OK, or any combination of monitor channels or channels from individual PPL racks. Donkey uses 3500 rack configuration software to program this alarm driver to meet the specific requirements of the application. 3500 monitors are certified as Zone 2 standards, including ATEX and North America, with multiple order approval options. The Zone 2 standard specifies that increasing the spacing requirements at higher voltages does not meet these spacing requirements for 3500/33 relays. Therefore, the use of multiple approval options for ordering 3500/33 relays has historically been limited to a lower level of voltage compared to a higher approved option for another arrangement. The use of higher voltage violates the hazardous area certificate and is associated with multiple approval options.
3500-33
The association between the North American Zone 2 standard and the CSA only approvals option has been reduced to 30Vrms to comply with the 61010-1 type test requirements. If 3500/33 is a part of functional safety (SIL) system, the functional safety certificate needs to limit the voltage. Higher voltages do not allow the use of Functional Safety (SIL) systems. Field wiring can be connected to conductors such as 3500/33 relays that are exposed to potential human contact. This may pose a risk of electric shock under high voltage. Customers should only use 3500/33 relays with voltages up to 30Vrms. Appropriate safety measures should be taken to prevent the danger of electric shock. The 16 channel relay module is a full height module that provides 16 relay outputs. You can place any number of channel relay modules transient data interface modules in any slot on the right side of the 16. Each output of the 16 channel relay module can be independently programmed to execute voting logic. Each relay in the module includes alarm drive logic. The programming of alarm drive logic uses AND and OR logic, and the following content can be used: n Alarm input alarms and dangerous states are not good. n individual measurement variables from any monitoring channel or any combination of monitor channels in the rack. You can use the 3500 framework to program and configure the software for alarm drive. The 16 channel relay module requires a 3500 rack configuration, version 3.3 or higher.
3500-33
The 16 channel relay module requires 3500 data acquisition software, version 2.40 or higher. The 16 channel relay module requires 3500 data display software, version=1.40 or higher. When ordering in multiples, the 3500 monitor is certified according to Zone 2 standards, including ATEX and North America. The standard for Zone 2 specifies the addition of spacing requirements at higher voltages. The 16 channel relay module does not meet these spacing requirements. Therefore, the module approval options ordered with multiples are limited to those with lower voltage ratios compared to other approval options. The use of higher voltage violates multiple approval options for hazardous area certificates related to the following. The North American Part 2 standard and CSA only approval related options have been downgraded to 30Vrms to meet the 61010-1 type test requirements. If the 1-6 channel relay module is a Functional Safety (SIL) system, the Functional Safety Certificate requires limited voltage. Higher voltages are not allowed for use in functional safety (SIL) systems.
