3500/40M Proximitor.是4通道位移监测器，接收本特利位移传感器的输入，对信号进行处理后生成各种振动和位移测星量，并将处理后的信号与用户可编程的报警设置点进行比较。可以使用3500框架组态软件对3500/40M的每个通道进行组态，使其具有如下功能:径向振动，轴向位移，差胀，轴偏心，REBAM，R滚动轴承振动注︰该监测器通道成对组态，一次最多可执行上述功能中的2个。通道1和通道2执行一个功能，通道3和通道4执行另—个功能或同—功能。3500/4OM监测器的主要功能为:通过连续不断地将机器振动当前值与组态中的报警值进行比较，并驱动报警系统，从而达到保护机器的目的;为操作人员和维护人员提供关键设备的振动信息。
3500-40M
BENTLY 3500-40M 监视器模块通过组态，每一通道通常将输入信号处理成静态值。每一静态值都有组态好的警告报警值，每两个静态值都可组态一个危险报警值。报警的延迟时间可通过软件设定。前面板LED(发光二极管）OK LED:指示3500/40M正常运行TX/RX LED:指示3500/40M正与3500框架内其它模块通讯Bypass LED: 指示3500/40M处于旁路模式传感器缓冲输出:前面板对应每一通道均有同轴接头，每一同轴接头都有短路保护。
3500-40M
The 3500/40M Proximitor is a 4-channel displacement monitor that receives inputs from Bentley displacement sensors, processes the signals to generate various vibration and displacement measurements, and compares the processed signals with user programmable alarm setpoints. Each channel of the 3500/40M can be configured using the 3500 rack configuration software to have the following functions: radial vibration, axial displacement, differential expansion, shaft eccentricity, REBAM, R rolling bearing vibration. Note: This monitor channel is configured in pairs and can perform up to 2 of the above functions at once. Channel 1 and channel 2 perform one function, while channel 3 and channel 4 perform another function or the same function. The main function of the 3500/4OM monitor is to continuously compare the current value of machine vibration with the alarm value in the configuration, and drive the alarm system to achieve the purpose of protecting the machine; Provide vibration information of critical equipment for operators and maintenance personnel.
3500-40M
The BENTLY 3500-40M monitor module is configured to typically process input signals into static values for each channel. Each static value has a configured warning alarm value, and each two static values can be configured with a danger alarm value. The delay time of the alarm can be set through software. Front panel LED (Light Emitting Diode) OK LED: indicates normal operation of 3500/40M TX/RX LED: indicates that 3500/40M is communicating with other modules in the 3500 rack Bypass LED: indicates that 3500/40M is in bypass mode Sensor buffered output: The front panel corresponds to each channel with coaxial connectors, and each coaxial connector has short-circuit protection.
3500-40M
