3500-53-133388-01 冗余电源模块机械检测系统的电子超速检测系统是高度可靠、快速响应的冗余转速表系统，专门用于机械的超速保护。3500/53 模块可用于组成2 选2 或3 选2(推荐)表决系统。安装超速检测系统的3500框架要求配备冗余电源。每一个超速检测模块接收一个涡流传感器或磁传感器的信号，输入信号的范围是＋10.0V 至 -24.0V。信号超出此范围，在模块内受限。适用于本特利3300 8mm 涡流传感器，3300 16mm 高温涡流传感器（HTPS），7200 5mm、8mm、11mm和14mm 涡流传感器，3300 RAM涡流传感器，或磁传感器。本特利3500/53超速保护模块，其设计是一个通道模块，它适用于两模块或三模块组的超速保护应用。模块接收来自趋近式传感器或磁电式传感器的转速脉冲输入信号，并使用这个输入信号驱动报警。为了实现机器保护目的，模块提供四种快速响应报警继电器输出。3500超速保护系统组态成两模块二选一表块或三模块三选二表决设置。
3500-53-133388-01
3500超速保护系统的最基本目的是提供通过连续比较当前机器转速与组态的报警设置点去驱动报警来实现机器保护和提供重要的机器转速信息给运行人员和维修人员。使用3500框架组态软件设置报警设置点。当从工厂发货时，3500/53没有组态。当需要时，为了实现所要求的监测功能，3500/53可安装到3500框架并组态。作为3500机器管理和保护系统的一部分，三通道3500/53超速保护系统可提供高可靠性超速保护。三通道超速保护系统包括3500框架，3500电源，框架接口模块和三个独立的超速保护模块。要求三个独立的传感器输入。3500/53模块可安装到框架接口模块右边的任何槽位(2-15)，但三个模块组，必须相邻安装。每个3500框架中只能安装一组超速保护系统。3500/53超速保护系统可安装在具有其它3500监测功能的3500框架中。三通道超速保护系统提供3个独立的转速监测通道。在报警时，三通道超速保护系统可组态成能提供3选2的表决功能。具有这种功能时，来自每个模块的报警输出进行比较，在继电器被驱动前，两个模块必须一致。
3500-53-133388-01
The electronic overspeed detection system of the 3500 53 133388-01 redundant power module mechanical detection system is a highly reliable and responsive redundant tachometer system specifically designed for mechanical overspeed protection. The 3500/53 module can be used to form a 2 out of 2 or 3 out of 2 (recommended) voting system. The 3500 rack for installing an overspeed detection system requires redundant power supplies. Each overspeed detection module receives a signal from an eddy current sensor or magnetic sensor, with an input signal range of+10.0V to -24.0V. The signal exceeds this range and is limited within the module. Suitable for Bentley 3300 8mm eddy current sensors, 3300 16mm high-temperature eddy current sensors (HTPS), 7200 5mm, 8mm, 11mm, and 14mm eddy current sensors, 3300 RAM eddy current sensors, or magnetic sensors. Bentley 3500/53 overspeed protection module is designed as a channel module, which is applicable to overspeed protection applications of two module or three module groups. The module receives a speed pulse input signal from a proximity sensor or magnetoelectric sensor and uses this input signal to drive an alarm. In order to achieve machine protection purposes, the module provides four types of fast response alarm relay outputs. The 3500 overspeed protection system is configured as a two module two choice meter block or a three module two choice voting setting.
3500-53-133388-01
The basic purpose of the 3500 overspeed protection system is to provide machine protection and important machine speed information to operators and maintenance personnel by continuously comparing the current machine speed with the configured alarm set points to drive alarms. Use the 3500 rack configuration software to set alarm setpoints. When shipped from the factory, the 3500/53 is not configured. When needed, in order to achieve the required monitoring functions, the 3500/53 can be installed and configured into the 3500 rack. As part of the 3500 machine management and protection system, the three channel 3500/53 overspeed protection system provides high reliability overspeed protection. The three channel overspeed protection system includes a 3500 rack, a 3500 power supply, a rack interface module, and three independent overspeed protection modules. Three independent sensor inputs are required. The 3500/53 module can be installed in any slot (2-15) on the right side of the frame interface module, but the three module groups must be installed adjacent. Only one set of overspeed protection systems can be installed in each 3500 rack. The 3500/53 overspeed protection system can be installed in a 3500 rack with other 3500 monitoring functions. The three channel overspeed protection system provides three independent speed monitoring channels. When giving an alarm, the three channel overspeed protection system can be configured to provide a voting function of 2 out of 3. When equipped with this function, the alarm outputs from each module must be compared and the two modules must be consistent before the relay is driven.
3500-53-133388-01
