500/92通信网关模块提供了广泛的所有机架监控值和状态的通信能力与过程控制和使用两者的其他自动化系统集成以太网TCP/IP和串行(RS232/RS422/RS485)通信能力。它还允许与3500机架配置软件进行以太网通信以及数据采集软件。支持的协议包括:ModiconModbus协议通过串行通信Modbus/TCP协议用于TCP/IP的串行Modbus的变体以太网通信专有的Bently Nevada协议用于与3500 Rack通信组态及数据采集软件包到3500/92的以太网连接是10BASE-T星型的RJ45连接配置以太网网络。3500/92支持通信接口、通信协议、以及除主功能外的其他3,500 /90原始版本的功能value Modbus寄存器。3500/92现在有一个可配置的Modbus寄存器方法最初处理的相同功能Modbus寄存器的主值。
3500-92
BENTLY 3500-92 通信网关模块利用高速内部网络从机架中的其他模块收集信息，包括带有时间戳的当前测量值、模块状态和当前警报状态。返回的确切数据类型取决于通道配置和模块类型。更新时间：3500 机架中所有模块的数据采集速率不会大于 1 秒，具体取决于机架的设计。对于 10BASE-T 星型配置以太网，3500/92 的以太网连接是 RJ45 连接。除了主要值 Modbus 寄存器外，3500/92 支持原始 3500/90 的通信接口、通信协议和附加功能。3500/92 中的主要值 Modbus 寄存器被可配置的 Modbus 寄存器实用程序所取代，现在可以提供相同的功能。
3500-92
The 500/92 communication gateway module provides a wide range of communication capabilities for all rack monitoring values and states, as well as integrated Ethernet TCP/IP and serial (RS232/RS422/RS485) communication capabilities for process control and other automation systems using both. It also allows Ethernet communication and data acquisition software with 3500 rack configuration software. The supported protocols include: ModiconModbus protocol, a variant of serial Modbus used for TCP/IP through serial communication Modbus/TCP protocol. The proprietary Bently Nevada protocol is used for Ethernet communication with 3500 Rack communication configuration and data acquisition software package. The Ethernet connection to 3500/92 is a 10BASE-T star RJ45 connection configuration Ethernet network. The 3500/92 supports communication interfaces, communication protocols, and other original versions of the 3500/90 function value Modbus registers in addition to the main function. The 3500/92 now has a configurable Modbus register method that initially handles the main values of the same functional Modbus register.
3500-92
The BENTLY 3500 92 communication gateway module utilizes a high-speed internal network to collect information from other modules in the rack, including current measured values with time stamps, module status, and current alarm status. The exact data type returned depends on the channel configuration and module type. Update time: The data collection rate of all modules in the 3500 rack will not exceed 1 second, depending on the design of the rack. For 10BASE-T star configuration Ethernet, the Ethernet connection for 3500/92 is RJ45 connection. In addition to the main value Modbus register, the 3500/92 supports the communication interface, communication protocol, and additional functions of the original 3500/90. The main value Modbus register in 3500/92 has been replaced by the configurable Modbus register utility and can now provide the same functionality.
