5304-MBP-PDPM通信模块缩放定义了由BIU与通道的输出电压。有两个预设缩放范围：+/-10伏和0至10电压。默认范围选择+/-10伏用于双极缩放。跨度和工程单位可以从–10000到+10000毫伏。另一个预设范围，0至+10伏用于单极缩放，同时提供跨度和工程单位为0至+10000毫伏。下图显示了两个预设范围。在选择双极或单极范围（见上文）后，每个点的缩放可以是通过改变其高或低工程单位和/或输出（跨度）值来定制。所选缩放值不限制硬件输出范围。
5304-MBP-PDPM
PLC控制器控制系统的地线包括系统地、地、交流地和保护地等。接地系统混乱对PLC控制器系统的干扰主要是各个接地点电位分布不均，不同接地点间存在地电位差，引起地环路电流，影响系统正常工作。例如电缆层必须一点接地，如果电缆层两端A、B都接地，就存在地电位差，有电流流过层，当发生异常状态如雷击时，地线电流将更大。MBP-PDPM模块是理想的解决方案在许多应用中，Modbus Plus连接可以用于将PROFIBUS DP从设备集成到-个系统。Modbus Plus网关功能强大模块设计与主从支持,可以轻松连接到其他Modbus设备(Modicon处理器和其他许多处理器)。结合具有PROFIBUS的DP设备支持，该模块提供了-个非常强大的接口PROFIBUS从设备是在使用今天的工业市场。模块的应用存在于大多数行业，尤其是制造业，石油和天然气，电力和食品加工。
5304-MBP-PDPM
The 5304-MBP-PDPM communication module scales and defines the output voltage between the BIU and the channel. There are two preset scaling ranges:+/-10 volts and 0 to 10 volts. The default range is+/-10 volts for bipolar scaling. The span and engineering units can range from -10000 to+10000 millivolts. Another preset range, 0 to+10 volts, is used for unipolar scaling, while providing spans and engineering units of 0 to+10000 millivolts. The following figure shows two preset ranges. After selecting a bipolar or unipolar range (see above), the scaling of each point can be customized by changing its high or low engineering units and/or output (span) values. The selected scaling value does not limit the hardware output range.
5304-MBP-PDPM
The ground wire of the PLC controller control system includes system ground, ground, AC ground, and protective ground. The interference of the chaotic grounding system on the PLC controller system is mainly due to the uneven distribution of potential at various grounding points, and the existence of ground potential differences between different grounding points, causing ground loop current and affecting the normal operation of the system. For example, the cable layer must be grounded at one point. If both ends A and B of the cable layer are grounded, there is a ground potential difference, and there is current flowing through the layer. When an abnormal state such as lightning strikes occurs, the ground wire current will be greater. The MBP-PDPM module is an ideal solution in many applications, where Modbus Plus connections can be used to integrate PROFIBUS DP from devices into a system. The Modbus Plus gateway features powerful module design and master-slave support, making it easy to connect to other Modbus devices (Modicon processors and many other processors). Combined with DP device support with PROFIBUS, this module provides a very powerful interface for PROFIBUS slave devices that are used in today’s industrial market. The application of modules exists in most industries, especially manufacturing, oil and gas, electricity, and food processing.
5304-MBP-PDPM
