A-B 6180W-12BPXPHDC 数字量输出触摸屏 产品详情：屏幕尺寸和分辨率： “6180W-12BPXPHDC” 可能指示触摸屏的尺寸和分辨率。尺寸和分辨率的选择会受到应用的要求和用户界面设计的影响。显示技术： 这款触摸屏可能采用液晶显示（LCD）技术，同时具备触摸屏以实现用户交互。数字量输出： 这款触摸屏可能具备数字量输出功能，可以控制数字输出信号，例如控制继电器、开关等。通信接口： 触摸屏可能配备多种通信接口，以实现与其他设备、网络或上层系统的连接。常见的接口包括以太网、串口、USB 等。操作系统和应用软件： 触摸屏可能运行特定的操作系统和应用软件，用于创建、运行和管理用户界面和控制逻辑。可视化界面： 操作员通过触摸屏可以查看图形化的可视化界面，监测过程状态、数据和参数，并进行设备控制和交互。工业环境适应性： 这类触摸屏通常设计用于工业环境，可能具备耐用性、防尘、防水等特性。多点触控： 现代触摸屏通常支持多点触控功能，允许用户使用多个手指进行操作和缩放 。产品是 Allen-Bradley Bulletin 6180W 产品线的一部分，用于或用于机器控制、维护，通常用于提供有关当前运行的应用程序的有价值信息。
6180W-12BPXPHDC
6180W-12BPXPHDC 可视化界面工作站具有集成键盘，可用于显示与启动过程、维修程序或维护步骤相关的数据。VersaView 产品系列提供多种不同的型号以及不同的标准额定值和性能型号可供选择。6180W-12BPXPHDC VersaView 1200W 工作站包括一个适用于苛刻环境的经济高效的平台，除数字键盘外，6180W-12BPXPHDC 工作站还具有 36 个可编程功能键，并通过可选卡支持 I/O。除此之外，6180W-12BPXPHDC 工作站还有两个 USB 端口和用于串行和并行通信、以太网 (10/100 M) 通信和音频连接的端口。此外，工作站还具有用于连接外部显示器的 VGA 输入。6180W-12BPXPHDC 工作站配备 24 位彩色 TFT 显示屏，分辨率为 800 x 600 像素，包括两个半长 PCI 插槽和一个全长 ISA 扩展插槽。这款 1200W 工作站型号配备 12 英寸显示屏尺寸，这款特殊性能型号配备电阻式触摸屏。还，该工作站使用直流电源运行，它包括一个 2 GHz Pentium IV 处理器和 512 MB RAM 该组件包括 80 GB 硬盘空间和一个 DVD/CD-RW 驱动器。输入电压范围为 19 至 32 伏直流电。
6180W-12BPXPHDC
A-B 6180W-12BPXPHDC Digital Output Touch Screen Product Details: Screen Size and Resolution: “6180W-12BPXPHDC” may indicate the size and resolution of the touch screen. The selection of size and resolution will be influenced by the requirements of the application and the design of the user interface. Display technology: This touch screen may use liquid crystal display (LCD) technology, and also have a touch screen for user interaction. Digital output: This touch screen may have a digital output function, which can control digital output signals, such as controlling relays, switches, etc. Communication interface: The touch screen may be equipped with multiple communication interfaces to connect with other devices, networks, or upper systems. Common interfaces include Ethernet, serial port, USB, etc. Operating system and application software: Touch screens may run specific operating systems and application software for creating, running, and managing user interfaces and control logic. Visualization interface: Operators can view a graphical visualization interface through the touch screen, monitor process status, data, and parameters, and perform equipment control and interaction. Industrial environment adaptability: This type of touch screen is usually designed for industrial environments and may have characteristics such as durability, dust prevention, and waterproofing. Multi touch: Modern touch screens typically support multi touch functionality, allowing users to operate and zoom with multiple fingers. The product is part of the Allen Bradley Bulletin 6180W product line, used for machine control, maintenance, and typically provides valuable information about currently running applications.
6180W-12BPXPHDC
The 6180W-12BPXPHDC visualization interface workstation has an integrated keyboard that can be used to display data related to startup processes, repair programs, or maintenance steps. The VersaView product series offers a variety of different models, as well as different standard ratings and performance models to choose from. The 6180W-12BPXPHDC VersaView 1200W workstation includes a cost-effective platform suitable for harsh environments. In addition to a digital keyboard, the 6180W-12BPXPHDC workstation also has 36 programmable function keys and supports I/O through optional cards. In addition, the 6180W-12BPXPHDC workstation also has two USB ports and ports for serial and parallel communication, Ethernet (10/100 M) communication, and audio connection. In addition, the workstation also has VGA input for connecting to external displays. The 6180W-12BPXPHDC workstation is equipped with a 24 bit color TFT display screen with a resolution of 800 x 600 pixels, including two half length PCI slots and a full length ISA expansion slot. This 1200W workstation model comes with a 12 inch display size, and this special performance model comes with a resistive touch screen. Additionally, the workstation runs on DC power and includes a 2 GHz Pentium IV processor and 512 MB of RAM, which includes 80 GB of hard disk space and a DVD/CD-RW drive. The input voltage range is 19 to 32 volts DC.
6180W-12BPXPHDC
