BENTLY 133819-01 运动控制器模块允许框架正常操作并且锁定任何组态变化。PROGRAM 模式允许框架正常运行并且允许对框架进行远程或本地组态。钥匙键可以在框架中的两个位置之间任意转还，允许开关保持在RUN 或PROGRAM 位置。锁定至RUN 方式可以防止任何非授权的框架组态。锁定至PROGRAM 方式可以在任何时间对框架进行远程组态。3500/22瞬态数据接口3500瞬态数据接口（TDI）是3500监测系统和本特利System 1TM 机械管理软件之间的接口。TDI结合了3500/20框架接口模块（RIM）和通讯处理器，如TDXnet的功能。TDI运行在3500框架的RIM插槽中，与M系列监测器（3500/40M、3500/42M等）配合使用，连续采集稳态和瞬态波形数据，并通过以太网将数据传送到主计算机软件。TDI具有标准的静态数据采集，但是采用可选的通道使能磁盘，也可采集瞬态或动态数据。TDI与以前的通讯处理器相比，除了将通讯处理器的功能集成到3500框架以外，还有其它几方面的改进。
133819-02
BENTLY 133819-01 运动控制器模块为全部框架提供通用功能，但并不是关键监测通道的组成部分，不影响整个监测系统的正确和常规运行。每个框架要求一个TDI或RIM。TDI只占用框架中的一个槽位，必须位于第一个插槽中（紧邻电源模块）。对于三重模块冗余（TMR）应用，3500系统要求TMR形式的TDI。除了所有标准TDI的功能，TMR TDI还具有“监测器通道比较功能”。通过选择监测器选项的安装功能，3500TMR组态执行监测表决功能。采用这种方式，TMR TDI连续比较三个冗余监测器的输出。如果TMR TDI检测出其中一个监测器的输出信息与其它两个监测器不相等（在组态的百分比之内），它就会向监测器发出错误指示，并在系统事件列表中加入一个事件。模件前面板的LED发光二极管的用途和各硬件转换开关与3500/20的相同，只是它的地址选择开关有127个地址可选。
133819-02
The BENTLY 133819-01 motion controller module allows the framework to operate normally and lock any configuration changes. The Program mode allows the framework to operate normally and allows for remote or local configuration of the framework. The key key can be rotated freely between two positions in the frame, allowing the switch to remain in the RUN or Program position. Locking to RUN mode can prevent any unauthorized framework configuration. Locking to the Program mode allows for remote configuration of the framework at any time. The 3500/22 Transient Data Interface (TDI) is the interface between the 3500 monitoring system and Bentley System 1TM mechanical management software. TDI combines the functions of the 3500/20 Rack Interface Module (RIM) and communication processors, such as TDXnet. TDI runs in the RIM slot of the 3500 rack and is used in conjunction with M-series monitors (3500/40M, 3500/42M, etc.) to continuously collect steady-state and transient waveform data, and transmit the data to the main computer software through Ethernet. TDI has standard static data collection, but optional channel enabled disks can also collect transient or dynamic data. Compared to previous communication processors, TDI has made several improvements in addition to integrating the functions of communication processors into the 3500 framework.
133819-02
The BENTLY 133819-01 motion controller module provides universal functionality for all frameworks, but is not a component of key monitoring channels and does not affect the correct and regular operation of the entire monitoring system. Each framework requires a TDI or RIM. TDI only occupies one slot in the frame and must be located in the first slot (adjacent to the power module). For Triple Modular Redundancy (TMR) applications, the 3500 system requires TDI in the form of TMR. In addition to all standard TDI functions, TMR TDI also has a “monitor channel comparison function”. By selecting the installation function of the monitor option, the 3500TMR configuration performs the monitoring voting function. In this way, TMR TDI continuously compares the outputs of three redundant monitors. If TMR TDI detects that the output information of one monitor is not equal to the other two monitors (within the configured percentage), it will issue an error indication to the monitor and add an event to the system event list. The purpose and hardware conversion switches of the LED on the front panel of the module are the same as those of the 3500/20, except that its address selection switch has 127 addresses to choose from.
133819-02
