bently3500/40(176449-01)机械振动监测位移模块前面板，本特利.内华达(Bently Nevada)公司的旋转机械在线状态监测系统bently3500,是为机械保护而设计的振动监测系统，涉及用户包括电力、石化、造纸、钢铁、机械和设备维修。本特利3500系统适用于压缩机、风机、制氧机、水泵、电机、汽轮机等机械的工程要求。其中汽轮机安全监视及保护系统(TSI)是比较典型的，可在线监测系统可连续测量和监测旋转机械和往复式机械的运转状态，对预防不平衡、不对中、轴裂痕和轴承损坏等预诊断提供重要的数据资料。
176449-01
可用的本特利(bently3500系列)监测器模块通道类型如下：径向振动、 轴向(侧向)位移 、差胀、 速度、 加速度、壳胀、 阀门位置、标准转速计、超速转速计、轴振动、 标准单斜面差胀 、 双斜面差胀 、零转速转速计等。bently3500 系统提供连续、在线监测功能，适用于机械保护应用，并完全符 合美国石油协会 API670 标准对该类系统的要求。BENTLEY 176449-01 监测位移模块该系统高度模块化的设计包括：必选项：框架 3500/05 ; 电源 3500/15;框架接口模块3500/22; 3500/01框架组态软件；振动监测器模块3500/42M等。
176449-01
可选项：键相器模块 3500/25;继电器模块 3500/32M或3500/33M；通讯网关模块3500/92。特点 :数字和模拟通讯 ；高度灵活的显示选项；软件可组态 ；更高的集成度/ 容错能力 ；报警/事件列表； API 670 标准 ；所有的模块和电源（当使用冗余电源时）可以在带电 情况下在框架中插拔，进的数据类型 3500 系统用于连续监测应用于多种行业的旋转和往复机械，尤其适用于要求极高可靠性和可用性的自动停机机械保护应用中。
176449-01
Bently3500/40 (176449-01) mechanical vibration monitoring displacement module front panel, Bently Nevada’s rotating machinery online condition monitoring system bently3500, is a vibration monitoring system designed for mechanical protection, involving users including power, petrochemical, papermaking, steel, machinery, and equipment maintenance. The Bentley 3500 system is suitable for engineering requirements of compressors, fans, oxygen generators, water pumps, motors, steam turbines, and other machinery. The turbine safety monitoring and protection system (TSI) is a typical example, which can continuously measure and monitor the operating status of rotating and reciprocating machinery through online monitoring systems. It provides important data for pre diagnosis of imbalance, misalignment, shaft cracks, and bearing damage.
176449-01
The available channel types for Bently 3500 series monitor modules are as follows: radial vibration, axial (lateral) displacement, differential expansion, velocity, acceleration, shell expansion, valve position, standard tachometer, overspeed tachometer, shaft vibration, standard single slope differential expansion, double slope differential expansion, zero speed tachometer, etc. The bently3500 system provides continuous and online monitoring functions, suitable for mechanical protection applications, and fully meets the requirements of the American Petroleum Institute API670 standard for such systems. BENTLEY 176449-01 Monitoring Displacement Module The highly modular design of this system includes: mandatory option: frame 3500/05; Power supply 3500/15; Framework interface module 3500/22; 3500/01 framework configuration software; Vibration monitor module 3500/42M, etc.
176449-01
Optional: Keyphasor module 3500/25; Relay module 3500/32M or 3500/33M; Communication gateway module 3500/92. Features: Digital and analog communication; Highly flexible display options; Software configurable; Higher integration/fault tolerance; Alarm/event list; API 670 standard; All modules and power supplies (when using redundant power supplies) can be plugged and unplugged in the frame under live conditions. The data type 3500 system is used for continuous monitoring of rotating and reciprocating machinery in various industries, especially suitable for automatic shutdown machinery protection applications that require high reliability and availability.
