BENTLY 350053 超速保护模块可提供高可靠性超速保护

3500/53超速保护模块，其设计是一个通道模块，它适用于两模块或三模块组的超速保护应用 3500/53超速保护模块，其设计是一个通道模块，它适用于两模块或三模块组的超速保护应用。模块接收来自趋近式传感器或磁电式传感器的转速脉冲输入信号，并使用这个输入信号驱动报警。为了实现机器保护目的，模块提供四种快速响应报警继电器输出。3500超速保护系统组态成两模块二选一表块或三模块三选二表决设置。3500超速保护系统的最基本目的是提供1)通过连续比较当前机器转速与组态的报警设置点去驱动报警来实现机器保护和2)提供重要的机器转速信息给运行人员和维修人员。使用3500框架组态软件设置报警设置点。当从工厂发货时，3500/53没有组态。当需要时，为了实现所要求的监测功能，3500/53可安装到3500框架并组态。

350053

作为3500机器管理和保护系统的一部分，三通道3500/53超速保护系统可提供高可靠性超速保护。三通道超速保护系统包括3500框架，3500电源，框架接口模块和三个独立的超速保护模块。要求三个独立的传感器输入。3500/53模块可安装到框架接口模块右边的任何槽位(2-15)，但三个模块组，必须相邻安装。每个3500框架中只能安装一组超速保护系统。3500/53超速保护系统可安装在具有其它3500监测功能的3500框架中。三通道超速保护系统提供3个独立的转速监测通道。在报警时，三通道超速保护系统可组态成能提供3选2的表决功能。具有这种功能时，来自每个模块的报警输出进行比较，在继电器被驱动前，两个模块必须一致。

350053

The 3500/53 overspeed protection module is designed as a channel module, which is applicable to overspeed protection applications of two module or three module groups. The 3500/53 overspeed protection module is designed as a channel module, which is applicable to overspeed protection applications of two module or three module groups. The module receives a speed pulse input signal from a proximity sensor or magnetoelectric sensor and uses this input signal to drive an alarm. In order to achieve machine protection purposes, the module provides four types of fast response alarm relay outputs. The 3500 overspeed protection system is configured as a two module two choice meter block or a three module two choice voting setting. The basic purpose of the 3500 overspeed protection system is to provide 1) drive alarms by continuously comparing the current machine speed with configured alarm setpoints to achieve machine protection, and 2) provide important machine speed information to operators and maintenance personnel. Use the 3500 rack configuration software to set alarm setpoints. When shipped from the factory, the 3500/53 is not configured. When needed, in order to achieve the required monitoring functions, the 3500/53 can be installed and configured into the 3500 rack.
