现场设备控制器(FDC) 280在单端口或双端口PLC、驱动器和其他分布式控制设备与EcoStruxure Foxboro DCS之间提供控制和以太网/串行接口。FDC 280优化了PLC等控制设备的集成，提高了灵活性，同时最大限度地减少了系统工程、占地面积和成本。特征：液晶显示器(LCD) —显示字母错误和实时角色和状态，支持多种网络连接—以太网、RS232、RS485、RS422，与CP plus FDSI解决方案相比，占地面积和布线减少50%，FCP280的在线映像升级(OLUG ),无需关闭流程，可下载和升级的协议驱动程序，在线。利益：减少工程工作量和安装占地面积，通过面向未来的设计降低拥有成本，为控制系统设计/实施提供更大的灵活性。
FCP280
应用程序：烃加工，化学和特种化学品，上游石油和天然气，发电，金属和采矿，水和废水，制药和生命科学。FCP280需要Foxboro DCS Control Core Services软件v9.0及以上版本。采用FCP280和该软件组成的系统称为ecostrucxure Foxboro DCS过程自动化系统。可选的双电缆底板支持四个PIO通道，但提供单独的A/B总线连接器以及用于可选时间频闪输入的专用连接器。从可选的双电缆底板到标准或紧凑型20O系列FBM的现场总线连接需要单独的A/B总线电缆以及FBM底板(RH926KW)上的双“D”连接适配器。
FCP280
The Field Device Controller (FDC) 280 provides control and Ethernet/serial interfaces between single or dual port PLCs, drivers, and other distributed control devices and EcoStruxure Foxboro DCS. The FDC 280 optimizes the integration of control equipment such as PLCs, improves flexibility, and minimizes system engineering, floor space, and costs. Features: Liquid Crystal Display (LCD) – displays letter errors and real-time roles and status, supports multiple network connections – Ethernet, RS232, RS485, RS422. Compared with CP plus FDSI solution, it reduces floor space and wiring by 50%. Online Image Upgrade (OLUG) for FCP280, no need to close the process, downloadable and upgradeable protocol driver, online. Benefits: Reduce engineering workload and installation footprint, reduce ownership costs through futuristic design, and provide greater flexibility for control system design/implementation.
FCP280
Applications: hydrocarbon processing, chemical and specialty chemicals, upstream oil and gas, power generation, metals and mining, water and wastewater, pharmaceuticals and life sciences. FCP280 requires Foxboro DCS Control Core Services software v9.0 and above. The system composed of FCP280 and this software is called the ecostrucxure Foxboro DCS process automation system. The optional dual cable backplane supports four PIO channels, but provides separate A/B bus connectors and dedicated connectors for optional time strobe inputs. The fieldbus connection from the optional dual cable backplane to the standard or compact 20O series FBM requires a separate A/B bus cable and a dual “D” connection adapter on the FBM backplane (RH926KW).
FCP280
PLC控制器本身的硬件采用积木式结构，各厂家产品结构大同小异。以日本欧姆龙C200HE为例，为总线模板框式结构，基本框架(CPU母板)上装有CPU模板，其它槽位装有I/O模板;如果I/O模板多时，可由CPU母板经I/O扩展电缆连接I/O扩展母板，在其上装I/O模板;另一种方法是配备远程I/O从站等。这些都说明了PLC厂家将硬件各部件均向用户开发，便于用户选用，配置成规模不等的PLC，而且这种硬件配置的开放性，为制造商、分销商(代理商)、系统集成商、最终用户带来很多方便，为营销供应链带来很大便利，这是一大成功经验。
FCP280
