MVI56-MNETC是PROSOFT技术的Modbus TCP/IP多客户端/服务器增强型网络接口模块。该模块特别与Controllogix平台兼容。模块占用Controllogix机箱的单个插槽，可用800VDC的功耗为5mA和3VDC可用电源的24mA。如果与附加指令AOC一起使用，则需要版本16或更高版本，而与提供的示例梯形图程序一起使用，则需要版本15或更高版本。此外，它还需要Prosoft配置生成器PCB来输入模块的配置。MVI56-MNETC支持多达30个Modbus客户端和20个Modbus服务器。该模块保证在多服务器架构中表现出更高的响应，在服务器突然离线的情况下最大限度地减少对其他服务器的影响，并通过提供对集成的数据访问来支持人机界面HMI，监控和数据采集。
MVI56-MNETC
MVI56E-MNETC支持多达30个MODBUS客户端和20个MODBUS服务器。该模块保证在多服务器架构中表现出增强的响应，在服务器突然离线的情况下最小化对其他服务器的影响，并通过提供集成数据访问来支持人机界面HMI、监控和数据采集SCADA以及分布式控制系统DCS。MVI56E-MNETC配有一个以太网通信端口，支持10/100 Mbps传输速率，能够检测自动交叉电缆的使用。它向后兼容以前的MVIS6E-MNETC版本，并发布了支持自定义数据映射的10，000字、16位整数。该模块还支持使用工业级CompactFlash卡进行灾难恢复和快速更换。这个CF卡也被称为个性模块。
MVI56-MNETC
MVI56 MNETC is a Modbus TCP/IP multi client/server enhanced network interface module based on PROSOFT technology. This module is particularly compatible with the Controllogix platform. The module occupies a single slot in the Controllogix chassis, with a power consumption of 5mA for 800VDC and 24mA for 3VDC. If used with the additional instruction AOC, version 16 or higher is required, while when used with the provided example ladder program, version 15 or higher is required. In addition, it also requires the Prosoft configuration generator PCB to input the module’s configuration. MVI56 MNETC supports up to 30 Modbus clients and 20 Modbus servers. This module ensures higher response in a multi server architecture, minimizing the impact on other servers in the event of a server suddenly going offline, and supporting human-machine interface HMI, monitoring, and data collection by providing integrated data access
MVI56-MNETC
MVI56E-MNETC supports up to 30 MODBUS clients and 20 MODBUS servers. This module ensures enhanced response in a multi server architecture, minimizing the impact on other servers in the event of a server suddenly going offline, and supporting human-machine interface HMI, monitoring and data acquisition SCADA, and distributed control system DCS by providing integrated data access. The MVI56E-MNETC is equipped with an Ethernet communication port that supports a 10/100 Mbps transmission rate and can detect the use of automatic crossover cables. It is backwards compatible with previous versions of MVIS6E-MNETC and has released 10000 word, 16 bit integers that support custom data mapping. This module also supports disaster recovery and rapid replacement using industrial grade CompactFlash cards. This CF card is also known as the personality module.
MVI56-MNETC
