扩展产品类型:UMC100.3 UC产品ID:1SAJ530000R1 100 EAN:4013614496929目录描述:UMC100.3 UC,电源110-240 V交流/DC, 6DI, 4DO, PTC输入详细描述:智能电机控制器UMC100.3 DC使10…240 V交流/DC电源，适用于过载保护。它可以连接到各种通信网络,并具有广泛的附加参数，以最大限度地保护电机。种类 制品低压产品和系统控制产品电机控制器通用电机控制器技术的标准:CAN/CSA C22.2编号60947-1 CAN/CSAC22.2编号60947-4-1 IEC/EN 60947-1 IEC/EN 60947-4-1 IEC/EN 60947-5-1 IEC/EN 60947-8 UL 508额定工作电压:主电路690伏交流电主电路1000伏交流电额定控制电源电压(Us):11040伏交流电/DC额定冲击耐受电压(U顽童):辅助电路4千伏额定工作电流:63 A额定频率:主电路50赫兹主电路60赫兹功率损耗。
UMC100
大约3.5瓦极数:3交流230伏数字输入的数量:DC 24V数字输入数量:6数字输出继电器的数量:3 DC 24V数字输出数量:一拧紧力矩:辅助电路0.5牛0控制电路0.5牛0行程等级:5E级10E级20E级30E级40E级安装位置:一..6 推荐螺丝刀:波兹迪夫1号模拟输入:0模拟输出:0 PCB涂层:不连接容量:1x 0.2-2.5毫米剥线长度:7毫米终端类型:螺丝端子环境的环境空气温度:操作0… + 60摄氏度存储25… +70摄氏度防护等级:IP20污染程度:3允许的最大工作高度:不降额20000抗振动能力符合。合IEC 60068-2-6:4g, …100赫兹抗冲击能力。符合IEC 60068-2-27:15g /1冲击/ 11毫秒RoHS状态:遵循欧盟指令2011/65/EU技术UL/CSA最大工作电压UL/CSA:辅助电路230 V交流/DC主电路600伏交流电连接容量UL /CSA:1x 28-12 AWG拧紧力矩UL /CSA:辅助电路8英寸磅控制电路8英寸磅规模
UMC100
Extended Product Type: UMC100.3 UC Product ID: SAJ530000R1 100 EAN: 4013614496929 Catalog Description: UMC100.3 UC, Power Supply 110-240 V AC/DC, 6DI, 4DO, PTC Input Detailed Description: Intelligent Motor Controller UMC100.3 DC enables 10… 240 V AC/DC power supply, suitable for overload protection. It can be connected to various communication networks and has a wide range of additional parameters to maximize motor protection. Category products Low voltage products and system control products Motor controllers General motor controller technology standards: CAN/CSA C22.2 Number 60947-1 CAN/CSA 22.2 Number 60947-4-1 IEC/EN 60947-1 IEC/EN 60947-4-1 IEC/EN 60947-5-1 IEC/EN 60947-8 UL 508 Rated working voltage: Main circuit 690V AC Main circuit 1000V AC Rated control power voltage (Us): 11040V AC/DC Rated impulse withstand voltage (U naughty) Auxiliary circuit 4 kV Rated working current: 63 A Rated frequency: Main circuit 50 Hz Main circuit 60 Hz Power loss.
UMC100
Approximately 3.5 watts of pole count: 3 AC 230 volts Number of digital inputs: DC 24V Number of digital inputs: 6 Number of digital output relays: 3 DC 24V Number of digital outputs: 1 Tightening torque: Auxiliary circuit 0.5 N 0 Control circuit 0.5 N 0 Stroke level: 5E level 10E level 20E level 30E level 40E level Installation position: 1 6 Recommended screwdriver: Potsdiff 1 analog input: 0 analog output: 0 PCB coating: not connected capacity: 1x 0.2-2.5mm stripping length: 7mm terminal type: screw terminal environment ambient air temperature: operation 0…+60 ° C storage 25…+70 ° C protection level: IP20 pollution level: 3 maximum allowable working height: not derated 20000 anti vibration ability meets the requirements. Compliant with IEC 60068-2-6:4g 100 Hz impact resistance. Compliant with IEC 60068-2-27:15g/1 impact/11 ms RoHS status: Following EU Directive 2011/65/EU technology UL/CSA maximum working voltage UL/CSA: Auxiliary circuit 230 V AC/DC Main circuit 600 V AC connection capacity UL/CSA: 1x 28-12 AWG Tightening torque UL/CSA: Auxiliary circuit 8 inch pounds Control circuit 8 inch pounds Scale
UMC100
