GE通用电气 IC694MDL940 继电器输出模块

IC694MDL940输出模块是GE 16点继电器输出模块。该输出控制器模块与 RX3i PACSystems 模块一起使用。它功能强大，并且具有多种有用的功能。它用于控制输出负载。

IC694MDL940 继电器触点是常开 (NO) 触点或 A 型触点。每个输出触点的额定最大负载为 2 安培先导负载，每个输出最大负载，而每个输出组设计为提供 4 安培的最大输出电流。此外，该模块的最小负载为 10 mA，最大浪涌电流为 5 A。每个继电器输出通道的响应时间为 15 ms，信号转换的最大值和模块的功耗为 7 mA @ 5VDC 总线电压和 135 mA 来自背板上的继电器 24V 总线。这些功耗额定值基于所有输出通道通电。

IC694MDL940 带有十六 (16) 个状态 LED 指示灯，每个指示灯代表单独的通道。通电的 LED 表示通电的输出，而断电的 LED 表示其他情况。该模块没有内置熔断器用于通道保护，因此用户可能需要安装外部熔断器来保护模块。

制造商：	GE/通用电气
系列：	RX3i PAC系统
型号：	IC694MDL940
产品类别：	继电器输出模块
输出点数：	16
频率：	50/60hz
产品覆盖范围：	DCS、PLC、TSL、SIS

The IC694MDL940 output module is a GE 16 point relay output module. This output controller module is used in conjunction with the RX3i PACSystems module. It is powerful and has multiple useful functions. It is used to control the output load.

The IC694MDL940 relay contacts are either normally open (NO) or A-type contacts. The rated maximum load of each output contact is a 2-ampere pilot load, with each output having a maximum load, and each output group designed to provide a maximum output current of 4 amperes. In addition, the minimum load of the module is 10 mA and the maximum surge current is 5 A. The response time of each relay output channel is 15 ms, and the maximum value of signal conversion and module power consumption are 7 mA @ 5VDC bus voltage and 135 mA from the relay 24V bus on the backplane. These power consumption ratings are based on all output channels being powered on.

IC694MDL940 comes with sixteen (16) status LED indicators, each representing a separate channel. The powered LED indicates the powered output, while the powered off LED indicates other situations. This module does not have built-in fuses for channel protection, so users may need to install external fuses to protect the module.
