IC693MDL753 PLC模拟量输出模块

IC693MDL753I/O模块是32点数字I/O模块。通用电气已为通用电气可编程逻辑控制器或PLCS系列90-30开发了IC693MDL753I/O模块。该模块的峰值电流消耗率为2.6亿安培,当它使用由PLC背板提供的5伏直流电压时。当输出点处于正常状态时,每一个输出点消耗16百万安培电流,而每一个输出点的指示器则消耗4.7百万安培电流。32分分为4组8组产出。当运行24伏特直流电压时,当组中的8个输出都处于正常状态时,每组点消耗1650万安培电流。当运行12伏特直流电压时,当组内的8个输出全部处于状态时,每个组消耗960万安培的电流。

IC693MDL753是90-30系列可编程逻辑控制器(PLC)系列的数字输出模块。该模块有三十二(32)个正逻辑输出通道，产生102 – 28.8的输出电压范围，标称电压为12 – 24 VDC。IC693MDL753以前由GE Fanuc Automation制造，现已被艾默生自动化收购。该模块带有输出分组，特别是四(4)组，每组八(8)个输出。每个输出组都有250伏的隔离，场侧和逻辑侧或光学隔离之间的电压为100伏。IC693MDL753的输出电流额定值为每点0.5安培，每组最大4安培，每组公共引脚最大3安培。它产生5.4安培的浪涌电流达10毫秒，而通态压降为0.3 VDC。关断状态下的漏电流为0.1 mA，两种信号转换的开和关响应时间典型值均为0.5 ms，IC693MDL753的内部功耗为260 mA，来自5 VDC背板。IC693MDL753兼容用作本地I/O和分布式I/O模块。它可以安装在机箱的任何可用插槽中，除了指定的CPU、通信适配器和专业模块插槽。IC693MDL753占用一个插槽，可以根据需要安装任意多个，但受主机控制器I/O容量和内存的限制。对于将电气负载连接到该离散输出模块，推荐的制造商电缆组件为IC693CBL315。

The IC693MDL753 I/O module is a 32-point digital I/O module. General Electric has developed the IC693MDL753I/O module for the General Electric Programmable Logic Controller or PLCS Series 90-30. The module has a peak current draw rate of 260 million amperes when it uses 5 volts DC supplied by the PLC backplane. When the output points are in the normal state, each output point draws 16 milliamps of current, while each output point indicator draws 4.7 milliamps of current. 32 points are divided into 4 groups of 8 outputs. When running 24 volts dc, each group of points draws 16.5 million amperes when all eight outputs in the group are in the normal state. When running 12 volts DC, each group draws 9.6 million amps when all 8 outputs in the group are in state.

The IC693MDL753 is a digital output module for the 90-30 series programmable logic controller (PLC) family. The module has thirty-two (32) positive logic output channels and produces an output voltage range of 102 – 28.8 with a nominal voltage of 12 – 24 VDC.The IC693MDL753 was formerly manufactured by GE Fanuc Automation and has been acquired by Emerson Automation. The module comes with output grouping, specifically four (4) groups of eight (8) outputs each. Each output group is isolated at 250 volts with 100 volts between the field side and the logic side or optical isolation.The IC693MDL753 has an output current rating of 0.5 amps per point, 4 amps maximum per group, and 3 amps maximum per common pin. It generates 5.4 amps of inrush current for up to 10 milliseconds with a pass-state voltage drop of 0.3 VDC. Leakage current in the off state is 0.1 mA, and the on and off response times for both signal transitions are 0.5 ms typical, and the IC693MDL753 consumes 260 mA of internal power from the 5 VDC backplane. The IC693MDL753 is compatible as a local I/O and distributed I/O module. It can be installed in any of the available slots in the chassis, except for the designated CPU, communications adapter, and specialty module slots.The IC693MDL753 occupies one slot and can be installed in as many as desired, subject to host controller I/O capacity and memory limitations. For connecting electrical loads to this discrete output module, the recommended manufacturer’s cable assembly is IC693CBL315.
