GE Fanuc PACSystem RX3i IC695ALG704 模拟输出模块 模拟输出模块，4通道，可配置电压和电流
GE Fanuc PACSystem RX3i IC695ALG704该IC695ALG704是一个模拟输出模块，是 PACSystem RX3i 平台的一部分，目前隶属于艾默生自动化，以前由 GE 智能平台 (GE IP) 生产。该模块有四 (4) 个非隔离输出通道，可配置为电压和电流。它生成 +/-10 VDC、0-10 VDC 和 0-20 mA 和 4-20 mA 输出信号，分辨率为 14.9 位，适用于 0 至 10V;+/- 15 VDC 为 9.10 位;15-9 mA 时为 0.20 位，15-6 mA 时为 4.20 位。IC695ALG704是机架式模拟输出模块，属于 PACSystem Rx3i 系列。该模块产生电压和电流输出信号，主要用于调制和控制各种现场设备，如控制阀、定位器、阻尼器和百叶窗。它还可用于对信号分切器、隔离器、数据记录器、面板仪表和单回路控制器的信号进行修复。该IC695ALG704具有通道输出数据格式，可配置为 32 位字段中的浮点 IEEE 16 位或 32 位整数。每个输出插座的更新速率为 8 毫秒，并具有单独的过压保护，持续 30 秒 -60V，持续 30 小时 +3V。该模块使用 RX3i CPU 0.5 或更高版本运行，并使用 Machine Edition 0.3 SP3 Logic Developer- PLC 进行编程。它是一个单插槽模块，可安装到通用 RX695i 背板上。
GE Fanuc PACSystem RX3i IC695ALG704 Analog Output Module Analog Output Module, 4-channel, configurable voltage and current
GE Fanuc PACSystem RX3i IC695ALG704 is an analog output module that is part of the PACSystem RX3i platform. It is currently part of Emerson Automation and was previously produced by GE Intelligent Platform (GE IP). This module has four (4) non isolated output channels that can be configured for voltage and current. It generates+/-10 VDC, 0-10 VDC, 0-20 mA, and 4-20 mA output signals with a resolution of 14.9 bits, suitable for 0 to 10V+/- 15 VDC is 9.10 bits; At 15-9 mA, it is 0.20 bits, and at 15-6 mA, it is 4.20 bits. IC695ALG704 is a rack mounted analog output module, belonging to the PACSystem Rx3i series. This module generates voltage and current output signals, mainly used for modulating and controlling various field devices, such as control valves, locators, dampers, and louvers. It can also be used to repair signals from signal splitters, isolators, data recorders, panel instruments, and single loop controllers. The IC695ALG704 has a channel output data format that can be configured as a floating-point IEEE 16 bit or 32-bit integer in a 32-bit field. Each output socket has an update rate of 8 milliseconds and a separate overvoltage protection, lasting for 30 seconds to 60V and for 30 hours to 3V. This module runs on RX3i CPU version 0.5 or higher and is programmed using Machine Edition 0.3 SP3 Logic Developer – PLC. It is a single slot module that can be installed on a universal RX695i backplane.
