BENTLY 3500/42M 176449-02 轴振动模块

产品细节说明：3500/42M 176449-02 BENTLY 轴振动模块

BENTLY 3500/42M 176449-02轴振动模块是一款高性能的监测设备，专为径向振动、轴向位移、偏心、REBAM和差胀测量而设计。它在工业自动化和机械设备监测领域具有广泛应用，特别是在能源、石油和天然气、化工等行业。

主要特点

1. 1. 多通道监测：作为一款可组态的4通道监测器模块，它能够同时监测多个参数，提高测试和测量的效率。
   2. 输入类型多样：除了接收电涡流传感器输入类型，还支持速度、加速度和双探头（速度和位移）输入类型及其相关的信号调节，如滤波和积分。
   3. 微分信号处理：能够从轴相对振动中提取机壳振动信号，为大型燃气和蒸汽轮机的轴绝对测量提供关键信息。
   4. 高精度测量：提供高达24位的分辨率和低噪声水平，确保测量结果的准确性。其优异的线性度和低漂移性能保证了宽动态范围内的准确测量结果。
   5. 灵活的输入范围：支持多种可调的输入范围，以适应不同信号源的幅度要求。
   6. 内置校准功能：具有内置的自动校准功能，可以在测量过程中对各通道进行校准，提高测量的精度和可靠性。
   7. 高速数据传输：采用PXIe总线接口，实现高速数据传输，确保采集的数据能够快速传输到计算机进行处理和分析。

BENTLY 3500/42M 176449-02

产品详情参数 ：3500/42M 176449-02 BENTLY 轴振动模块

1. 输入电压：24VDC
2. 输入电流：100mA
3. 工作温度：-40°C至+85°C
4. 振动测量范围：未提供具体范围，但适用于广泛的振动监测需求。
5. 温度测量范围：-40°C至+125°C（若模块包含温度监测功能）
6. 通信接口：可能包括Modbus RS485等

3500/42M 176449-02 应用领域：

BENTLY 3500/42M 176449-02轴振动模块在多个工业领域都有应用，包括但不限于：

• 能源行业：监测发电厂、电厂和其他能源设施中的发电机、涡轮机、风力涡轮等旋转设备的轴承状态。
• 石油和天然气行业：在石油钻井、炼油厂和天然气处理设施中监测泵、压缩机和其他旋转设备的振动水平。
• 化工行业：监测搅拌器、离心机、泵等旋转设备的振动情况，预测设备故障并采取适当的维护措施。

Product details: 3500/42M 176449-02 BENTLY shaft vibration module

BENTLY 3500/42M 176449-02 shaft vibration module is a high-performance monitoring device designed specifically for radial vibration, axial displacement, eccentricity, REBAM, and differential expansion measurement. It has a wide range of applications in industrial automation and mechanical equipment monitoring, especially in industries such as energy, oil and natural gas, and chemical industry.

main features

Multi channel monitoring: As a configurable 4-channel monitoring module, it can simultaneously monitor multiple parameters, improving the efficiency of testing and measurement.
Diverse input types: In addition to receiving eddy current sensor input types, it also supports speed, acceleration, and dual probe (speed and displacement) input types and their related signal conditioning, such as filtering and integration.
Differential signal processing: capable of extracting casing vibration signals from relative shaft vibrations, providing critical information for absolute shaft measurements of large gas and steam turbines.
High precision measurement: Provides up to 24 bit resolution and low noise levels to ensure the accuracy of measurement results. Its excellent linearity and low drift performance ensure accurate measurement results over a wide dynamic range.
Flexible input range: Supports multiple adjustable input ranges to adapt to the amplitude requirements of different signal sources.
Built in calibration function: With built-in automatic calibration function, it can calibrate each channel during the measurement process, improving measurement accuracy and reliability.
High speed data transmission: The PXIE bus interface is used to achieve high-speed data transmission, ensuring that the collected data can be quickly transmitted to the computer for processing and analysis.
BENTLY 3500/42M 176449-02
Product details and parameters: 3500/42M 176449-02 BENTLY axis vibration module
Input voltage: 24VDC
Input current: 100mA
Working temperature: -40 ° C to+85 ° C
Vibration measurement range: No specific range provided, but suitable for a wide range of vibration monitoring needs.
Temperature measurement range: -40 ° C to+125 ° C (if the module includes temperature monitoring function)
Communication interface: may include Modbus RS485, etc

3500/42M 176449-02 Application areas:

The BENTLY 3500/42M 176449-02 shaft vibration module has applications in multiple industrial fields, including but not limited to:

Energy industry: monitoring the bearing status of rotating equipment such as generators, turbines, and wind turbines in power plants, power plants, and other energy facilities.
The oil and gas industry: monitors the vibration levels of pumps, compressors, and other rotating equipment in oil drilling, refineries, and natural gas processing facilities.
Chemical industry: Monitor the vibration of rotating equipment such as mixers, centrifuges, and pumps, predict equipment failures, and take appropriate maintenance measures.
