Schneider TM251MESE 可编程控制器 成都阳光

产品细节说明：TM251MESE Schneider 可编程控制器

• • 以太网端口：Ethernet 1（10BASE-T/100BASE-TX，2端铜电缆）和Ethernet 2（10BASE-T/100BASE-TX，1端铜电缆）
  • 最大连接数：8个网络通讯协议服务器和16个网络通讯协议客户
  • 支持的协议：以太网/IP、FTP服务器、SoMachine protocol等
• 编程与软件支持：
  • 编程软件：可使用SoMachineBasic软件编程
  • 数据传输：可通过SD卡、嵌入式Web服务器等提升数据传输性能
  • 访问方式：可通过以太网无限访问，并支持使用任何移动设备
• 物理特性：
  • 紧凑格式，支持扩展总线Modicon TM3
  • 含有SD卡插槽、嵌入式Web和FTP服务器
  • 串行线路和USB端口
• 环保与健康安全：
  • 带有Green Premium TM标签，致力于提供一流环保性能的产品
  • 符合RoHS/REACH标准，无汞、无PVC
• 通信与连接：
  • 支持CANopen或Modbus TCP，方便连接至SCADA、MES和ERP
  • 支持多种通信协议和连接方式，如USB、RS232/RS485界面、双端口以太网等
• 认证与标准：
  • 符合ANSI/ISA 12-12-01、CSA C22.2 No 142/213、EN/IEC 61131-2:2007等标准
  • 船用规格（LR, ABS, DNV, GL）
  • 产品认证包括CULus、CSA等

TM251MESE

产品详情参数 ：TM251MESE Schneider 可编程控制器

• I/O扩展模块：
  • 本地I/O体系：支持7个I/O拓展模块
  • 远程I/O体系：支持最多14个I/O拓展模块
• 电源与功耗：
  • 瞬间峰值电流：50 A
  • 功耗范围：32.6～40.4 W（最大数量的I/O扩展模块时）
• 存储容量：
  • 系统内存：64 MB RAM
  • 数据备份：128 MB 内置闪存卡
  • 用户项目备份：可使用≤16 GB的SD卡（可选）

TM251MESE Schneider 应用领域：

1. 工业自动化与控制：
   • 主要应用于模块化机器和分布式架构领域，为工业自动化提供可靠的控制解决方案。
   • 变速驱动器和远程输入/输出可以方便地连接在开路和SAE J1939机器总线上，或通过以太网网络连接，实现高效的数据传输和控制。
2. 控制系统集成：
   • 作为嵌入M251式以太网端口的设备，已安装了多种服务，如FTP客户端/服务器、Web服务器、SQL客户端、SNMP客户端/服务器V1和V2、OPC UA服务器、SNTP客户端和DNS客户端服务。这些功能使得TM251MESE能够轻松集成到各种控制系统架构中，用于远程监控和维护机器。
3. 行业应用：
   • 环保：在环保领域，TM251MESE可以协助实现自动化控制，提高环保设备的运行效率和稳定性。
   • 化工：在化工生产过程中，TM251MESE可以实现对各种化工设备的精确控制，确保生产过程的稳定性和安全性。
   • 能源：在能源领域，如太阳能、风场等可再生能源的应用中，TM251MESE可以协助实现能源的有效利用和智能控制。
   • 建材：在建材生产过程中，TM251MESE可以实现对生产线的自动化控制，提高生产效率和产品质量。
   • 电子：在电子制造领域，TM251MESE可以实现对生产设备的精确控制，确保电子产品的生产质量和性能。

Product details: TM251MESE Schneider programmable controller
Ethernet ports: Ethernet 1 (10BASE-T/100BASE-TX, 2-end copper cable) and Ethernet 2 (10BASE-T/100BASE-TX, 1-end copper cable)
Maximum number of connections: 8 network communication protocol servers and 16 network communication protocol clients
Supported protocols: Ethernet/IP, FTP server, SoMachine protocol, etc
Programming and software support:
Programming software: SoMachineBasic software can be used for programming
Data transmission: Data transmission performance can be improved through SD cards, embedded web servers, etc
Access method: Unlimited access through Ethernet and supports the use of any mobile device
Physical properties:
Compact format, supports expansion bus Modicon TM3
Contains SD card slots, embedded web, and FTP servers
Serial line and USB port
Environmental protection and health and safety:
With the Green Premium TM label, committed to providing products with first-class environmental performance
Compliant with RoHS/REACH standards, mercury free and PVC free
Communication and Connection:
Supports CANopen or Modbus TCP for easy connection to SCADA, MES, and ERP
Supports multiple communication protocols and connection methods, such as USB, RS232/RS485 interface, dual port Ethernet, etc
Certification and Standards:
Complies with standards such as ANSI/ISA 12-12-01, CSA C22.2 No 142/213, EN/IEC 61131-2:2007, etc
Marine specifications (LR, ABS, DNV, GL)
Product certifications include CULus, CSA, etc

Product details and parameters: TM251MESE Schneider programmable controller
I/O expansion module:
Local I/O system: supports 7 I/O expansion modules
Remote I/O system: supports up to 14 I/O expansion modules
Power supply and power consumption:
Instantaneous peak current: 50 A
Power consumption range: 32.6-40.4 W (maximum number of I/O expansion modules)
Storage capacity:
System memory: 64 MB RAM
Data backup: 128 MB built-in flash memory card
User project backup: Can use ≤ 16 GB SD card (optional)

TM251MESE Schneider application areas:
Industrial Automation and Control:
Mainly applied in the fields of modular machines and distributed architecture, providing reliable control solutions for industrial automation.
The variable speed drive and remote input/output can be conveniently connected to open circuits and SAE J1939 machine buses, or connected through Ethernet networks to achieve efficient data transmission and control.
Control system integration:
As a device embedded in the M251 Ethernet port, various services have been installed, such as FTP client/server, web server, SQL client, SNMP client/server V1 and V2, OPC UA server, SNTP client, and DNS client services. These features enable TM251MESE to be easily integrated into various control system architectures for remote monitoring and maintenance of machines.
Industry applications:
Environmental protection: In the field of environmental protection, TM251MESE can assist in achieving automated control, improving the operational efficiency and stability of environmental protection equipment.
Chemical Industry: In the chemical production process, TM251MESE can achieve precise control of various chemical equipment, ensuring the stability and safety of the production process.
Energy: In the field of energy, such as the application of renewable energy such as solar energy and wind farms, TM251MESE can assist in achieving effective energy utilization and intelligent control.
Building materials: In the production process of building materials, TM251MESE can achieve automated control of the production line, improve production efficiency and product quality.
Electronics: In the field of electronic manufacturing, TM251MESE can achieve precise control over production equipment, ensuring the production quality and performance of electronic products.
