产品细节说明：PLX31-EIP-SIE PROSOFT 工业以太网网关
PROSOFT PLX31-EIP-SIE是一款功能强大、性能稳定的工业以太网网关，它实现了EtherNet/IP与西门子工业以太网之间的无缝通信。通过其丰富的技术规格和强大的数据交换能力，该产品为工业自动化领域提供了可靠的解决方案。
- 嵌入式EDS附加配置文件：简化集成并减少调试时间
- SD卡插槽（SD卡可选）：用于存储配置文件，可用于灾难恢复
- ProSoft Discovery Service：允许PC查看网关并更改其默认IP地址，而无需在同一子网中
PLX31-EIP-SIE
产品详情参数 ：PLX31-EIP-SIE PROSOFT 工业以太网网关
- 电源
- 标称电压：24V直流电
- 电压范围：10V至36V直流电
- 电流负载：标称24VDC时300mA，最大610mA（10V至36VDC）
- 工作环境
- 工作温度：-25°C至70°C（-13°F至158°F）
- 储存温度：-40°C至80°C（-40°F至176°F）
- 湿度：5%至95%相对湿度，无冷凝
- 以太网端口
- 类型：10/100Mbit半双工RJ45连接器
- 电气隔离：1500Vrms，50至60Hz，持续60秒（符合IEC 60950:1991）
- 广播风暴弹性：小于或等于每秒5000 [ARP]帧，持续时间小于或等于5分钟
PLX31-EIP-SIE PROSOFT 应用领域：
PROSOFT PLX31-EIP-SIE广泛应用于工业自动化领域，特别是在需要EtherNet/IP与西门子工业以太网之间高效通信的场合。它可以用于食品、农业、文体、能源、交通等多个行业，提高生产效率和数据交换的可靠性。
Product Details: PLX31-EIP-SIE PROSOFT Industrial Ethernet Gateway
PROSOFT PLX31-EIP-SIE is a powerful and stable industrial Ethernet gateway that enables seamless communication between EtherNet/IP and Siemens Industrial Ethernet. Through its rich technical specifications and powerful data exchange capabilities, this product provides a reliable solution for the industrial automation field.
Embedded EDS Additional Configuration Files: Simplify Integration and Reduce Debugging Time
SD card slot (SD card optional): used for storing configuration files, can be used for disaster recovery
ProSoft Discovery Service: Allow PC to view gateway and change its default IP address without being in the same subnet
Product Details and Parameters: PLX31-EIP-SIE PROSOFT Industrial Ethernet Gateway
Power Supply
Nominal voltage: 24V DC
Voltage range: 10V to 36V DC
Current load: 300mA at nominal 24VDC, maximum 610mA (10V to 36VDC)
work environment
Working temperature: -25 ° C to 70 ° C (-13 ° F to 158 ° F)
Storage temperature: -40 ° C to 80 ° C (-40 ° F to 176 ° F)
Humidity: 5% to 95% relative humidity, no condensation
Ethernet port
Type: 10/100Mbit half duplex RJ45 connector
Electrical isolation: 1500Vrms, 50 to 60Hz, lasting for 60 seconds (compliant with IEC 60950:1991)
Broadcast storm resilience: less than or equal to 5000 frames per second [ARP], with a duration of less than or equal to 5 minutes
Application areas of PLX31-EIP-SIE PROSOFT:
PROSOFT PLX31-EIP-SIE is widely used in the field of industrial automation, especially in situations where efficient communication between EtherNet/IP and Siemens Industrial Ethernet is required. It can be used in multiple industries such as food, agriculture, culture and sports, energy, transportation, etc., to improve production efficiency and reliability of data exchange.
