产品细节说明：RLX2-IFH24E Prosoft 工业级 2.4 GHz 无线中继器
- 网络结构：支持点对点 (PTP) 和智能以太网 (SSE) 模式。
- 传输距离：在 PTP 模式下，使用高增益天线最远可达 15 英里 。
- 安全性：采用专有的跳频算法和 128 位 AES 加密算法，确保数据传输安全 。
- 配置与监控：通过 ControlScape 软件快速配置，包含 OPC 服务器软件，允许通过 OPC 客户端软件监控网络状态 。
- 应用领域：广泛适用于工业自动化、机器人技术、过程控制、远程监控、智能交通系统、楼宇自动化和智能家居等场景
RLX2-IFH24E
产品详情参数 ：RLX2-IFH24E Prosoft 工业级 2.4 GHz 无线中继器
- 供电范围：10-30 VDC。
- 工作温度：标准为 -25°C 至 +70°C，扩展为 -40°C 至 +65°C
- 工作频率：2.400 GHz 至 2.4835 GHz，位于国际免许可的 2.4 GHz 带宽下 。
- 数据速率：最高可达 1.1 Mbps。
- 输出功率：可调节，范围从 100 mW 至 1W。
- 接收灵敏度：在 1.1 Mbps 时为 -98 dBm，345 kbps 时为 -106 dBm。
- 接口：包括 1 个以太网接口、1 个 24VDC 电源接口、1 个 232 串口、1 个 485 串口和 1 个天线接口 。
RLX2-IFH24E Prosoft 应用领域：
RLX2-IFH24E 工业中继器以其长距离通信能力、稳定性和安全性，在多个领域有着广泛的应用前景。它还获得了多项认证，包括 ATEX、cULus、FCC、Gost-R、IC 和 UL/cUL: Class 1, Div 2，确保其在各种工业环境中的安全性和合规性
Product details: RLX2-IFH24E Prosoft industrial grade 2.4 GHz wireless repeater
Network architecture: Supports point-to-point (PTP) and intelligent Ethernet (SSE) modes.
Transmission distance: In PTP mode, using a high gain antenna can reach up to 15 miles.
Security: Using proprietary frequency hopping algorithm and 128 bit AES encryption algorithm to ensure data transmission security.
Configuration and Monitoring: Quickly configure through ControlScape software, including OPC server software, allowing monitoring of network status through OPC client software.
Application areas: Widely applicable to scenarios such as industrial automation, robotics technology, process control, remote monitoring, intelligent transportation systems, building automation, and smart homes
Product details and parameters: RLX2-IFH24E Prosoft industrial grade 2.4 GHz wireless repeater
Power supply range: 10-30 VDC.
Working temperature: standard from -25 ° C to+70 ° C, extended to -40 ° C to+65 ° C
Operating frequency: 2.400 GHz to 2.4835 GHz, located within the international unlicensed 2.4 GHz bandwidth.
Data rate: up to 1.1 Mbps.
Output power: adjustable, ranging from 100 mW to 1W.
Receiver sensitivity: -98 dBm at 1.1 Mbps and -106 dBm at 345 kbps.
Interfaces: including 1 Ethernet interface, 1 24VDC power interface, 1 232 serial port, 1 485 serial port, and 1 antenna interface.
RLX2-IFH24E Prosoft application areas:
The RLX2-IFH24E industrial repeater has broad application prospects in multiple fields due to its long-distance communication capability, stability, and security. It has also obtained multiple certifications, including ATEX, cULus, FCC, Gost-R, IC, and UL/cUL: Class 1, Div 2, ensuring its safety and compliance in various industrial environments
