Schneider TM3AQ4 4路模拟量输出模块 成都阳光熹禾

产品细节说明：TM3AQ4 Schneider 4路模拟量输出模块

• 电缆类型和长度：推荐使用屏蔽双绞线，最大长度可达 30 米（98 英尺）。
• 环保和健康安全：产品符合 RoHS/REACH 标准，不含有毒重金属如汞和 PVC，带有 Green Premium™ 标签，致力于提供环保性能优越的产品 。
• 应用领域：适用于 Modicon M221、M241、M251 和 M262 逻辑控制器，是 MachineStruxure 输入/输出系统的一部分，提供直观的机械自动化解决方案 。
• 设计特点：透明、环保的产品设计，支持远程定位（长达 5 米）和总线扩展系统，提供灵活的解决方案 。
• 状态 LED 指示：模块上有 PWR 绿色 LED 指示灯，亮起表示已接通 TM3 总线电源，熄灭表示已断开 TM3 总线电源 。

TM3AQ4

产品详情参数 ：TM3AQ4 Schneider 4路模拟量输出模块

• 输出通道：模块提供 4 个独立的 12 位模拟输出通道，可以输出电压或电流信号 。
• 信号类型：支持的信号类型包括 0 至 10 Vdc 和 -10 至 +10 Vdc 的电压信号，以及 0 至 20 mA 和 4 至 20 mA 的电流信号 。
• 电源规格：模块的额定电源为 24 Vdc，电源电压范围是 20.4 Vdc 至 28.8 Vdc 。
• 连接类型：TM3AQ4 提供可插拔螺钉端子块，而其变体 TM3AQ4G 提供可插拔卡簧端子块，以适应不同的安装需求 。

TM3AQ4 Schneider 应用领域：

TM3AQ4 模块的连接器插入和拔出至少可耐受 100 次，5 Vdc 内部总线上的最大电流在无负载时为 40 mA，满负载时为 60 mA；24 Vdc 内部总线上的最大电流为 0 mA；外部 24 Vdc 时的最大电流在无负载时为 50 mA，满负载时为 125 mA 。适用于 Modicon M221、M241、M251 和 M262 逻辑控制器，是 MachineStruxure 输入/输出系统的一部分，提供直观的机械自动化解决方案

Product details: TM3AQ4 Schneider 4-channel analog output module
Cable type and length: It is recommended to use shielded twisted pair cables, with a maximum length of up to 30 meters (98 feet).
Environmental Protection and Health Safety: The product complies with RoHS/REACH standards, does not contain toxic heavy metals such as mercury and PVC, and comes with Green Premium ™ Labels are committed to providing products with superior environmental performance.
Application areas: Suitable for Modicon M221, M241, M251, and M262 logic controllers, it is part of the MechaniStruxure input/output system and provides intuitive mechanical automation solutions.
Design features: Transparent and environmentally friendly product design, supporting remote positioning (up to 5 meters) and bus expansion system, providing flexible solutions.
Status LED indicator: There is a PWR green LED indicator on the module, which lights up to indicate that the TM3 bus power has been connected, and goes out to indicate that the TM3 bus power has been disconnected.
Product details and parameters: TM3AQ4 Schneider 4-channel analog output module
Output channel: The module provides 4 independent 12 bit analog output channels, which can output voltage or current signals.
Signal types: The supported signal types include voltage signals from 0 to 10 Vdc and -10 to+10 Vdc, as well as current signals from 0 to 20 mA and 4 to 20 mA.
Power specifications: The rated power supply of the module is 24 Vdc, and the power supply voltage range is 20.4 Vdc to 28.8 Vdc.
Connection type: TM3AQ4 provides pluggable screw terminal blocks, while its variant TM3AQ4G provides pluggable card spring terminal blocks to meet different installation requirements.
TM3AQ4 Schneider Application Fields:

The connector insertion and extraction of the TM3AQ4 module can withstand at least 100 times, and the maximum current on the 5 Vdc internal bus is 40 mA under no load and 60 mA under full load; The maximum current on the 24 Vdc internal bus is 0 mA; The maximum current at external 24 Vdc is 50 mA when unloaded and 125 mA when fully loaded. Suitable for Modicon M221, M241, M251, and M262 logic controllers, it is part of the MechaniStruxure input/output system and provides an intuitive mechanical automation solution
