产品细节说明：TM3AI8 Schneider 8 路模拟量输入模块
- 输入通道：模块提供 8 个独立的 12 位模拟输入通道，可以接收电压或电流信号。
- 信号类型：支持的信号类型包括 0 至 10 Vdc 和 -10 至 +10 Vdc 的电压信号，以及 0 至 20 mA、4 至 20 mA 和 0 至 20 mA 扩展型、4 至 20 mA 扩展型的电流信号。
- 电源规格：模块的额定电源为 24 Vdc，电源电压范围是 20.4 Vdc 至 28.8 Vdc。
- 连接类型：TM3AI8 提供可插拔螺钉端子块，而其变体 TM3AI8G 提供可插拔卡簧端子块，以适应不同的安装需求。
- 电缆类型和长度：推荐使用屏蔽双绞线，最大长度可达 30 米（98 英尺）。
- 状态 LED 指示：模块上有 PWR 绿色 LED 指示灯，亮起表示已接通 TM3 总线电源，熄灭表示已断开 TM3 总线电源 。
TM3AI8
产品详情参数 ：TM3AI8 Schneider 8 路模拟量输入模块
- 重量：TM3AI8 模块的重量为 110 克（3.88 盎司），TM3AI8G 模块的重量为 100 克（3.52 盎司）。
- 额定电源电压：24 Vdc，电源范围 20.4…28.8 Vdc，连接器插入/拔出耐久性至少 100 次。
- 5 Vdc 内部总线上的最大电流：无负载时 35 mA，满负载时 35 mA，24 Vdc 内部总线上的最大电流为 0 mA，外部 24 Vdc 时的最大电流无负载时 30 mA，满负载时 40 mA。
TM3AI8 Schneider 应用领域：
TM3AI8 模块适用于多种工业自动化应用，可以与 Modicon M221、M241、M251 和 M262 逻辑控制器配合使用，是 MachineStruxure 输入/输出系统的一部分。模块的高精度和高分辨率特性使其非常适合用于精确测量和控制。
Product details: TM3AI8 Schneider 8-channel analog input module
Input channels: The module provides 8 independent 12 bit analog input channels that can receive voltage or current signals.
Signal types: The supported signal types include voltage signals from 0 to 10 Vdc and -10 to+10 Vdc, as well as current signals from 0 to 20 mA, 4 to 20 mA, 0 to 20 mA extension, and 4 to 20 mA extension.
Power specifications: The rated power supply of the module is 24 Vdc, and the power supply voltage range is 20.4 Vdc to 28.8 Vdc.
Connection type: TM3AI8 provides pluggable screw terminal blocks, while its variant TM3AI8G provides pluggable card spring terminal blocks to meet different installation requirements.
Cable type and length: It is recommended to use shielded twisted pair cables, with a maximum length of up to 30 meters (98 feet).
Status LED indicator: There is a PWR green LED indicator on the module, which lights up to indicate that the TM3 bus power has been connected, and goes out to indicate that the TM3 bus power has been disconnected.
Product details and parameters: TM3AI8 Schneider 8-channel analog input module
Weight: The weight of the TM3AI8 module is 110 grams (3.88 ounces), and the weight of the TM3AI8G module is 100 grams (3.52 ounces).
Rated power supply voltage: 24 Vdc, power supply range 20.4… 28.8 Vdc, connector insertion/extraction durability of at least 100 times.
The maximum current on the 5 Vdc internal bus is 35 mA at no load and 35 mA at full load. The maximum current on the 24 Vdc internal bus is 0 mA, and the maximum current on the external 24 Vdc bus is 30 mA at no load and 40 mA at full load.
TM3AI8 Schneider Application Fields:
The TM3AI8 module is suitable for various industrial automation applications and can be used in conjunction with Modicon M221, M241, M251, and M262 logic controllers. It is part of the input/output system of the MechaniStruxure. The high precision and resolution characteristics of the module make it very suitable for precise measurement and control.
