ABB REL561 1MRK002496-AC 线路差动保护终端 成都阳光熹禾

产品细节说明:REL561 1MRK002496-AC ABB 线路差动保护终端

1. 线路差动保护：应用电流差动保护比较进入和离开受保护的架空线路或电缆的电流，为输电、分输电和配电网络提供分相真电流差动保护。
2. 数字系统：该终端是一个数字系统，适用于现代数字通信系统，包括多路复用和路由交换系统。
3. 主/主设计：电流微分函数采用主/主设计，利用电流幅度和相位角分别评估两端的每个相电流（分离矢量比较）。
4. CT饱和检测：所有电流都由CT饱和检测器单独监控，以最大限度地减少对电流互感器的要求，并在CT饱和的情况下增加两端受影响阶段的稳定程度。
5. 传输延迟补偿：能够连续补偿传输过程中的延迟，确保两端数据同步。
6. 通信接口：支持多种现代以太网、串行和现场总线协议，如以太网/IP和Profinet，使得它无需任何额外的硬件即可在网络中作为主、扫描器或控制器工作。

REL561 1MRK002496-AC

产品详情参数:REL561 1MRK002496-AC ABB 线路差动保护终端

• 输入电压：100-240V AC，频率50/60Hz。
• 工作温度：-20°C至+60°C。
• 使用环境：常温常压。
• 结构形式：模块式。
• 安装方式：现场安装。

REL561 1MRK002496-AC ABB 应用领域:

该产品广泛应用于输电、分输电和配电网络的电流差动保护，是一个数字系统，适用于现代数字通信系统，包括多路复用和路由交换系统。电流比较以每相为基础进行比较，避免了电流求和方法的问题，并为单极跳闸提供了相位选择信息 。

Product details: REL561 1MRK002496-AC ABB line differential protection terminal

Line differential protection: The application of current differential protection compares the current entering and leaving the protected overhead line or cable, providing phase separated true current differential protection for transmission, sub transmission, and distribution networks.

Digital System: This terminal is a digital system suitable for modern digital communication systems, including multiplexing and routing switching systems.

Main/Main Design: The current differential function adopts the main/main design, which evaluates each phase current at both ends separately using current amplitude and phase angle (separated vector comparison).

CT saturation detection: All currents are monitored separately by CT saturation detectors to minimize the requirements on current transformers and increase the stability of the affected stages at both ends in the event of CT saturation.

Transmission delay compensation: It can continuously compensate for the delay during the transmission process, ensuring data synchronization at both ends.

Communication interface: Supports multiple modern Ethernet, serial, and fieldbus protocols such as Ethernet/IP and Profinet, allowing it to function as a master, scanner, or controller in the network without any additional hardware.

Product details and parameters: REL561 1MRK002496-AC ABB line differential protection terminal
Input voltage: 100-240V AC, frequency 50/60Hz.
Working temperature: -20 ° C to+60 ° C.
Usage environment: normal temperature and pressure.
Structural form: modular.
Installation method: On site installation.
REL561 1MRK002496-AC ABB application areas:

This product is widely used for current differential protection in transmission, sub transmission, and distribution networks. It is a digital system suitable for modern digital communication systems, including multiplexing and routing switching systems. Current comparison is based on each phase, avoiding the problem of current summation methods and providing phase selection information for single pole tripping.
