ABB RER103 总线连接模块 成都阳光熹禾

产品细节说明:RER103 ABB 总线连接模块

RER 103 是 ABB 公司生产的一款总线连接模块，它在工业自动化和控制系统中用于实现不同设备或系统之间的通信和数据传输。这个模块的主要功能是将来自 LON®/SPA 总线的光信号转换为 RE500 设备的电 RS-485 信号，以及将电信号转换为光信号，从而实现不同通信协议之间的转换。

1. 接口转换：能够将光纤 SPA、LON 和 IEC 60870-5-103 总线上的光信号转换为电 RS-485 信号，适用于 RE500 设备。
2. 总线拓扑支持：支持环型（Loop）和星型（Star）两种总线拓扑结构。
3. 线路空闲状态选择：用户可以根据需要选择线路空闲状态下的光信号是亮（Light On）还是灭（Light Off）。
4. 安装方式：模块设计为插入式，可以方便地插入到主机设备的 D 型亚小型连接器上。

RER103

产品详情参数:RER103 ABB 总线连接模块

• 尺寸：宽度 35.0 mm，高度 73.0 mm，深度 20.0 mm。
• 工作温度范围：-40°C 至 +70°C。
• 电源：由主机设备提供（5V DC），辅助电源供应约为 0.4W。
• 最大负载：1.25 Mbps。
• 最大数据传输速率：1.25 Mbps。

RER103 ABB 应用领域:

RER 103 是 ABB 公司生产的一款总线连接模块，它主要用于实现不同设备或系统之间的通信和数据传输。这个模块能够将来自 LON®/SPA 总线的光信号转换为 RE500 设备的电RS-485信号，反之亦然。RER 103 模块可以插入主机设备的 D 型亚小型连接器中，并可以与任何提供有 9 针 D 型连接器的 RE500 设备一起使用。RER 103 模块在工业自动化、过程控制、能源管理等领域中发挥着重要作用，它们允许不同的设备或系统通过总线协议进行连接和通信，实现数据的共享和控制。尽管 RER 103 自 2011 年起已不再是活跃产品，但它仍然在许多现有的系统中发挥作用。

Product Details: RER103 ABB Bus Connection Module

RER 103 is a bus connection module produced by ABB, which is used in industrial automation and control systems to achieve communication and data transmission between different devices or systems. The main function of this module is to integrate data from LON ®/ The optical signal of SPA bus is converted into the electrical RS-485 signal of RE500 device, and the electrical signal is converted into optical signal to achieve the conversion between different communication protocols.

Interface conversion: capable of converting optical signals on fiber optic SPA, LON, and IEC 60870-5-103 buses into electrical RS-485 signals, suitable for RE500 devices.

Bus topology support: Supports both Loop and Star bus topologies.

Line idle state selection: Users can choose whether the light signal in the line idle state is on (Light On) or off (Light Off) according to their needs.

Installation method: The module is designed as a plug-in type, which can be easily inserted into the D-type sub miniature connector of the host device.

Product details and parameters: RER103 ABB bus connection module
Dimensions: Width 35.0 mm, height 73.0 mm, depth 20.0 mm.
Working temperature range: -40 ° C to+70 ° C.
Power supply: Provided by the host device (5V DC), with an auxiliary power supply of approximately 0.4W.
Maximum load: 1.25 Mbps.
Maximum data transmission rate: 1.25 Mbps.
RER103 ABB application areas:

RER 103 is a bus connection module produced by ABB, mainly used to achieve communication and data transmission between different devices or systems. This module is capable of integrating data from LON ®/ The optical signal of SPA bus is converted into the electrical RS-485 signal of RE500 device, and vice versa. The RER 103 module can be inserted into the D-type sub miniature connector of the host device and can be used with any RE500 device that provides a 9-pin D-type connector. The RER 103 module plays an important role in industrial automation, process control, energy management, and other fields, allowing different devices or systems to connect and communicate through bus protocols, achieving data sharing and control. Although RER 103 is no longer an active product since 2011, it still plays a role in many existing systems.
