3500/77M 176449-07 BENTLY 往复式气缸压力监控器 成都阳光熹禾

产品细节说明:3500/77M 176449-07 BENTLY 往复式气缸压力监控器

1. 压力测量与监控：
   • 该监控器通过压力传感器接收输入信号，并对这些信号进行调节，以适应各种往复式压缩机的压力测量需求。
   • 它能够测量和监控与单个腔室相关的多个压力参数，包括排出压力、吸入压力、最大压力、最小压力以及压缩比。
2. 警报功能：监控器将监测到的参数与用户可编程的警报设定点进行持续比较，一旦参数超出设定范围，将驱动警报系统，从而保护机器免受潜在损害。
3. 数据处理与显示：监控器不仅提供实时的压力数据，还可能具备数据处理功能，将收集到的数据进行分析和整理，以便操作人员更好地理解机器的运行状态。

3500/77M 176449-07

产品详情参数:3500/77M 176449-07 BENTLY 往复式气缸压力监控器

• 固件和软件版本：
  • 需要特定版本的固件和软件才能正常工作，包括3500/77M模块固件版本L，以及3500/01、3500/02和3500/03等软件版本。
• 环境适应性：
  • 工作温度范围：-30°C至+65°C（存储温度：-40°C至+85°C）
  • 湿度：95%，无冷凝
• 尺寸与重量：
  • 尺寸（高x宽x深）：241.3毫米x 24.4毫米x 241.8毫米（约9.50英寸x 0.96英寸x 9.52英寸）
  • 重量：约2.6kg
• 通讯方式：无线通讯

3500/77M 176449-07 BENTLY  应用领域:

该监控器广泛应用于需要精确监测和控制气缸压力的往复式压缩机系统中，如石油、化工、能源等行业。3500/77M 176449-07 BENTLY是一款功能强大、技术先进的往复式气缸压力监控器，能够为往复式压缩机的安全运行提供有力保障。3500/77M 176449-07 BENTLY是一款由本特利（Bently）生产的往复式气缸压力监控器，它主要用于监测和控制往复式压缩机的气缸压力，为机器提供保护，并为操作和维护人员提供重要的机器信息。

Product details: 3500/77M 176449-07 BENTLY reciprocating cylinder pressure monitor
Pressure measurement and monitoring:
This monitor receives input signals through pressure sensors and adjusts these signals to meet the pressure measurement requirements of various reciprocating compressors.
It can measure and monitor multiple pressure parameters related to a single chamber, including discharge pressure, suction pressure, maximum pressure, minimum pressure, and compression ratio.
Alarm function: The monitor continuously compares the monitored parameters with the user programmable alarm set points. Once the parameters exceed the set range, the alarm system will be activated to protect the machine from potential damage.
Data processing and display: The monitor not only provides real-time pressure data, but may also have data processing functions to analyze and organize the collected data, so that operators can better understand the operating status of the machine.
Product details and parameters: 3500/77M 176449-07 BENTLY reciprocating cylinder pressure monitor
Firmware and software versions:
Specific versions of firmware and software are required to function properly, including firmware version L for the 3500/77M module, as well as software versions 3500/01, 3500/02, and 3500/03.
Environmental adaptability:
Operating temperature range: -30 ° C to+65 ° C (storage temperature: -40 ° C to+85 ° C)
Humidity: 95%, no condensation
Size and weight:
Dimensions (height x width x depth): 241.3 millimeters x 24.4 millimeters x 241.8 millimeters (approximately 9.50 inches x 0.96 inches x 9.52 inches)
Weight: Approximately 2.6kg
Communication method: wireless communication

3500/77M 176449-07 BENTLY Application Fields:

This monitor is widely used in reciprocating compressor systems that require precise monitoring and control of cylinder pressure, such as in industries such as petroleum, chemical, and energy. 3500/77M 176449-07 BENTLY is a powerful and technologically advanced reciprocating cylinder pressure monitor that provides strong guarantees for the safe operation of reciprocating compressors. 3500/77M 176449-07 BENTLY is a reciprocating cylinder pressure monitor produced by Bently. It is mainly used to monitor and control the cylinder pressure of reciprocating compressors, provide protection for machines, and provide important machine information for operators and maintenance personnel.
