VIBRO-METER VM600 IOC4T 200-560-000-111 200-560-101-017 输入/输出（I/O）模块 成都阳光熹禾

产品细节说明:VM600 IOC4T 200-560-000-111 200-560-101-017 输入/输出（I/O）模块

VM600 IOC4T模块作为VM600系列机械设备的信号接口，安装在VM600机架的后部，并通过两个连接器直接连接到机架背板。该模块支持多种输入和输出类型，包括触点输入、模拟输入、脉冲输入以及继电器输出等，使MPC4卡能够连接到各种传感器和执行器。

1. 输入类型：
   • 触点输入：支持24VDC或120VAC。
   • 模拟输入：支持0-10VDC或0-20mA。
   • 脉冲输入：支持0-10kHz。
2. 输出类型：
   • 继电器输出：提供多个继电器输出，可用于报警信号等。
   • 模拟输出：支持0-10VDC或0-20mA。
3. 动态信号输入与滤波：
   • VM600 IOC4T模块具有动态信号输入功能，并经过滤波以防止电磁干扰（符合欧共体/EC标准）。
4. 继电器特性：
   • 继电器名称：RL1至RL4。
   • 类型：PE014005。
   • 触点排列：每个继电器具有1个常闭（NC）或1个常开（NO）触点（用户可配置）。
   • 额定电压：250VAC。
   • 额定电流：5AAC。

VM600 IOC4T 200-560-000-111 200-560-101-017

产品详情参数:VM600 IOC4T 200-560-000-111 200-560-101-017 输入/输出（I/O）模块

1. 工作条件：
   • 工作温度：-25至65°C（-13至149°F）。
   • 存储温度：-40至85°C（-40至185°F）。
   • 湿度：工作时0至90%（无冷凝），存储时0至95%（无冷凝）。
2. 其他功能：
   • 支持实时插拔（可热插拔）。
   • 提供EMI保护。
   • 配备红色LED指示灯，提供操作的视觉指示。

VM600 IOC4T 200-560-000-111 200-560-101-017 应用领域:

VM600 IOC4T模块广泛应用于各种工业设备的状态监测和控制系统中。它作为MPC4机械保护卡的信号接口，能够连接多种传感器和执行器，实现设备状态的实时监测和控制。此外，该模块还与直接逻辑dl05、dl06、d2-250-1、d2-260和d4-450等CPU兼容，确保与现有系统的无缝集成。

Product Details: VM600 IOC4T 200-560-000-111 200-560-101-017 Input/Output (I/O) Module

The VM600 IOC4T module serves as the signal interface for the VM600 series mechanical equipment, installed at the rear of the VM600 rack and directly connected to the rack backplane through two connectors. This module supports multiple input and output types, including contact input, analog input, pulse input, and relay output, enabling the MPC4 card to connect to various sensors and actuators.

Input type:
Contact input: Supports 24VDC or 120VAC.
Analog input: Supports 0-10VDC or 0-20mA.
Pulse input: Supports 0-10kHz.
Output type:
Relay output: Provides multiple relay outputs, which can be used for alarm signals, etc.
Analog output: Supports 0-10VDC or 0-20mA.
Dynamic signal input and filtering:
The VM600 IOC4T module has dynamic signal input function and is filtered to prevent electromagnetic interference (compliant with EC/EC standards).
Relay characteristics:
Relay names: RL1 to RL4.
Type: PE014005.
Contact arrangement: Each relay has one normally closed (NC) or one normally open (NO) contact (user configurable).
Rated voltage: 250VAC.
Rated current: 5AAC.
Product Details and Parameters: VM600 IOC4T 200-560-000-111 200-560-101-017 Input/Output (I/O) Module
Working conditions:
Working temperature: -25 to 65 ° C (-13 to 149 ° F).
Storage temperature: -40 to 85 ° C (-40 to 185 ° F).
Humidity: 0 to 90% during operation (no condensation), 0 to 95% during storage (no condensation).
Other functions:
Support real-time plugging (hot swappable).
Provide EMI protection.
Equipped with red LED indicator lights, providing visual guidance for operation.
VM600 IOC4T 200-560-000-111 200-560-101-017 Application areas:

The VM600 IOC4T module is widely used in the status monitoring and control systems of various industrial equipment. As the signal interface of MPC4 mechanical protection card, it can connect various sensors and actuators to achieve real-time monitoring and control of equipment status. In addition, the module is compatible with CPUs such as DL05, DL06, D2-250-1, D2-260, and D4-450, ensuring seamless integration with existing systems.
