IGCT是将GTO芯片与反并联二极管和门极驱动电路集成在-起，再与其门极驱动器在外围以低电感方式连接,结合了晶体管的稳定关断能力和晶闸管低通态损耗的优点，在导通阶段发挥晶闸管的性能，关断阶段呈现晶体管的特性。IGCT 具有电流大、阻断电压高、开关频率高、可靠性高、结构紧凑、低导通损耗等特点,而且造成本低，成品率高，有很好的应用前景。己用于电力系统电网装置(100MVA) 和的中功率工业驱动装置(5MW)IGCT在中压变频器 领域内成功的应用了11年的时间(到09年为止)，
5SHX1060H0003
由于IGCT的高速开关能力无需缓冲电路，因而所需的功率元件数目更少,运行的可靠性大大增高。IGCT集IGBT (绝缘门极双极性晶体管)的高速开关特性和GTO (门极关断品闸管)的高阻断电压和低导通损耗特性于一体，一般触发信号通过光纤传输到IGCT单元。在ACS6000的有缘整流单元的相模块里，每相模块由IGCT 和二极管、钳位电容组成，由独立的门极供电单元GUSP为其提供能源。
5SHX1060H0003
IGCT integrates GTO chips with anti parallel diodes and gate drive circuits, and then connects them with their gate drivers in a low inductance manner on the periphery. It combines the stable turn-off ability of transistors and the advantages of low on state losses of thyristors, exerting the performance of thyristors during the conduction phase and presenting transistor characteristics during the turn-off phase. IGCT has the characteristics of high current, high blocking voltage, high switching frequency, high reliability, compact structure, low conduction loss, and low manufacturing cost, high yield, and has good application prospects. The medium power industrial drive device (5MW) IGCT, which has been used in power system grid devices (100MVA) and medium power industrial drive devices, has been successfully applied in the field of medium voltage frequency converters for 11 years (until 2009). Due to the high-speed switching ability of IGCT without the need for buffer circuits, the number of power components required is fewer, and the reliability of operation is greatly improved. IGCT integrates the high-speed switching characteristics of IGBT (insulated gate bipolar transistor) and the high blocking voltage and low conduction loss characteristics of GTO (gate turn off thyristor). Generally, the trigger signal is transmitted to the IGCT unit through optical fiber. In the phase module of the edge rectifier unit of ACS6000, each phase module is composed of IGCT, diode, and clamp capacitor, and is powered by an independent gate power supply unit GUSP.
5SHX1060H0003
专业销售世界各大电气品牌产品产品海外直接采购，正品库存，价格优惠售后保修，型号齐全，一样的产品，不一样的价格与服务。
大量供应原装进口DCS系统配件，PLC系统配件。主营:ABB、GE发那科、Bentl本特利、Triconex英维思、Woodward伍德沃德、Foxboro福克斯波罗、Westinghouse西屋/Emerson艾默生、Reliance瑞恩、SchneiderModicon施耐德莫迪康、A-B、HIMA黑马、Motorola摩托罗拉、Kollmorgen科尔摩根Bosch/Rexroth/博世力上乐，NI,YOKOGAWA横河，等各大品牌的DCS系统配件，机器人系统配件，大型伺服系统停产备件。
