IGBT系列高频驱动板，主要采用SG3525A作为PWM脉冲形成， 输出脉冲频率范围20KHZ- 60KHZ,脉冲间隔互为180度， 死区时间可以自行调整。可适用于IGBT全桥逆变串联谐振感应加热装置调频调功。
5SHX1445H0002
功率范围: 10KW- 1 20KW,该控制板接线少，控制集中,没有调试，工作电源电压为三路交流双18V/1A及四个22V/0.5A的电源。具有过流，过压，却水，多种状态指示，并提供开关型霍尔保护接口和线性霍尔保护接口，有全桥逆变IGBT驱动电路，此板可直接组装IGBT高频感应加热装置。
5SHX1445H0002
The IGBT series high-frequency drive board mainly uses SG3525A as PWM pulse formation, with an output pulse frequency range of 20KHZ -60KHZ, pulse intervals of 180 degrees each other, and dead time adjustable. Suitable for frequency and power regulation of IGBT full bridge inverter series resonant induction heating devices. Power range: 10KW -1 20KW, this control board has few wiring, centralized control, and no debugging. The working power supply voltage is three AC dual 18V/1A and four 22V/0.5A power supplies. It has various status indicators such as overcurrent, overvoltage, cooling water, and provides switch type Hall protection interfaces and linear Hall protection interfaces. It also has a full bridge inverter IGBT drive circuit, which can directly assemble IGBT high-frequency induction heating devices.
5SHX1445H0002
