5SHY4045L0001 3BHB018162R0001集成栅极换流晶闸管IGCT(Intergrated Gate Commutated Thyristors)是1996年问世的用于巨型电力电子成套装置中的新型电力半导体器件。IGCT是一 种基于GTO结构、利用集成栅极结构进行栅极硬驱动、采用缓冲层结构及阳极透明发射极技术的新型大功率半导体开关器件，有晶闸管的通态特性及晶体管的开关特性。
5SHY4045L0001 3BHB018162R0001由于采用了缓冲结构以及浅层发射极技术,因而使动态损耗降低了约50%，另外，此类器件还在-个芯片上集成了具有良好动态特性的续流二极管 ，从而以其独特的方式实现了晶闸管的低通态压降、高阻断电压和晶体管稳定的开关特性有机结合.IGCT使变流装置在功率、可靠性、开关速度、效率、成本、重量和体积等方面都取得了巨大进展，给电力电子成套装置带来了新的飞跃。5SHY4045L0001 3BHB018162R0001是将GTO芯片与反并联二极管和栅极驱动电路集成在-起， 再与其栅极驱动器在外围以低电感方式连接,结合了晶体管的稳定关断能力和晶闸管低通态损耗的优点，在导通阶段发挥晶闸管的性能，关断阶段呈现晶体管的特性。
5SHY4045L0001
5SHY4045L0001 3BHB018162R0001具有电流大、电压高、开关频率高、可靠性高、结构紧凑、损耗低等特点，而且造成本低，成品率高,有很好的应用前景。5SHY4045L0001 3BHB018162R0001采用晶闸管技术的GTO是常用的大功轩关器件，它相对于采用晶体管技术的IGBT在截止电压上有更高的性能，但广泛应用的标准GTO驱动技术造成不均匀的开通和关断过程，需要高成本的dv/dt和di/dt吸收电路和较大功率的栅极驱动单元，因而造成可靠性下降，价格较高，也不利于串联。5SHY4045L0001 3BHB018162R0001但是,在大功率MCT技术尚未成熟以前，IGCT已经成为高压大功率低频交流器的优选方案。
5SHY4045L0001
5SHY4045L0001 3BHB018162R0001 adopts a buffering structure and shallow emitter technology, which reduces dynamic losses by about 50%. In addition, this type of device integrates freewheeling diodes with good dynamic characteristics on one chip, thus achieving a unique combination of low pass state voltage drop, high blocking voltage, and transistor stable switching characteristics of thyristors. IGCT enables the converter to achieve power, reliability Significant progress has been made in terms of switch speed, efficiency, cost, weight, and volume, bringing new leaps to complete power electronic devices. 5SHY4045L0001 3BHB018162R0001 integrates a GTO chip with an anti parallel diode and gate driver circuit, and then connects it with its gate driver in a low inductance manner on the periphery. It combines the stable turn-off ability of transistors and the advantages of low on state losses of thyristors, and utilizes the performance of thyristors during the conduction phase, while presenting transistor characteristics during the turn-off phase.
5SHY4045L0001
5SHY4045L0001 3BHB018162R0001 has the characteristics of high current, high voltage, high switching frequency, high reliability, compact structure, low loss, and low manufacturing cost, high yield, and has good application prospects. 5SHY4045L0001 3BHB018162R0001 GTO using thyristor technology is a commonly used high-power gate device, which has higher performance in cutoff voltage compared to IGBTs using transistor technology. However, the widely used standard GTO driving technology causes uneven opening and closing processes, requiring high cost dv/dt and di/dt absorption circuits and high-power gate driving units, resulting in reduced reliability, higher prices, and unfavorable series connection. However, before the maturity of high-power MCT technology, IGCT has become the preferred solution for high-voltage and high-power low-frequency AC converters.
5SHY4045L0001
专业销售世界各大电气品牌产品产品海外直接采购，正品库存，价格优惠售后保修，型号齐全，一样的产品，不一样的价格与服务。
大量供应原装进口DCS系统配件，PLC系统配件。主营:ABB、GE发那科、Bentl本特利、Triconex英维思、Woodward伍德沃德、Foxboro福克斯波罗、Westinghouse西屋/Emerson艾默生、Reliance瑞恩、SchneiderModicon施耐德莫迪康、A-B、HIMA黑马、Motorola摩托罗拉、Kollmorgen科尔摩根Bosch/Rexroth/博世力上乐，NI,YOKOGAWA横河，等各大品牌的DCS系统配件，机器人系统配件，大型伺服系统停产备件。
