线路板按层数来分的话分为单面板，双面板,和多层线路板三个大的分类。
首先是单面板，在最基本的PCB上，零件集中在其中-面，导线则集中在另-面上。因为导线只出现在其中一面, 所以就称这种PCB叫作单面线路板。单面板通常制作简单,造价低，但是缺点是无法应用于太复杂的产品上。双面板是单面板的延伸，当单层布线不能满足电子产品的需要时，就要使用双面板了。双面都有覆铜有走线，组可以通过过孔来导通两层之间的线路，使之形成所需要的网络连接。
810-073479-215
810-073479-215
多层板是指具有三层以上的导电图形层与其间的绝缘材料以相隔层压而成，其间导电图形按要求互连的印制板。多层线路板是电子信息技术向高速度、多功能、大容量、小体积、薄型化、轻量化方向发展的产物。线路板按特性来分的话分为软板(FPC),硬板(PCB), 软硬结合板(FPCB)。
810-073479-215
810-073479-215
Circuit boards can be divided into three major categories based on the number of layers: single panel, double-sided board, and multi-layer circuit board.
Firstly, there is a single panel. On the most basic PCB, the parts are concentrated on one side and the wires are concentrated on the other side. Because wires only appear on one side, this type of PCB is called a single sided circuit board. Single panel production is usually simple and cost-effective, but the disadvantage is that it cannot be applied to products that are too complex. Double panel is an extension of a single panel, and when single-layer wiring cannot meet the needs of electronic products, double-sided boards are used. Both sides are covered with copper and have wiring, and the group can conduct the lines between the two layers through vias to form the required network connection.
810-073479-215
专业销售世界各大电气品牌产品产品海外直接采购，正品库存，价格优惠售后保修，型号齐全，一样的产品，不一样的价格与服务。大量供应原装进口DCS系统配件，PLC系统配件。主营:ABB、GE发那科、Bentl本特利、Triconex英维思、Woodward伍德沃德、Foxboro福克斯波罗、Westinghouse西屋/Emerson艾默生、Reliance瑞恩、SchneiderModicon施耐德莫迪康、A-B、HIMA黑马、Motorola摩托罗拉、Kollmorgen科尔摩根Bosch/Rexroth/博世力上乐，NI,YOKOGAWA横河，等各大品牌的DCS系统配件，机器人系统配件，大型伺服系统停产备件
