Allen-Bradley 的 1785-CHBM ControlNet PLC-5 热背盒模块是安装在 PLC-5 处理器上的备份模块，允许启用 ControlNet 的 PLC-5 控制器在备份模式下运行。1785-CHBM具有100K字的非易失性用户存储器容量，其存储器可以通过移除模块上的跳线来赋予写保护。该模块旨在与 1785-L20C15、-L40C15 或 -L80C5 处理器完全兼容，并符合 CISPR 11：组 1，A 类（具有适当的外壳）辐射规范。1785-CHBM 的 IEC 额定工作温度范围为 0-600 C （32-140 0F），相对湿度水平为 5-95%，无冷凝，额定储存温度范围为 –40-85 0C （–40-185 0F）。经过测试和额定，可承受 2-10Hz 时 500 的工作振动和 30G 的工作冲击而不会降额，并且可以承受 50G 的非工作冲击。 它重 7.88 克，通过了 UL、CE、C-TICK 和 CSA 认证。
1785-CHBM
Allen Bradley’s 1785-CHBM ControlNet PLC-5 Hot Backpack Module is a backup module installed on the PLC-5 processor, allowing ControlNet enabled PLC-5 controllers to run in backup mode. The 1785-CHBM has a non-volatile user memory capacity of 100K words, and its memory can be granted write protection by removing jumpers on the module. This module is designed to be fully compatible with 1785-L20C15, – L40C15, or – L80C5 processors and comply with CISPR 11: Group 1, Class A (with appropriate enclosure) radiation specifications. The IEC rated operating temperature range of 1785-CHBM is 0-600 C (32-140 0F), relative humidity level is 5-95%, non condensing, and rated storage temperature range is -40-85 0C (-40-185 0F). After testing and rating, it can withstand 500 working vibrations at 2-10Hz and 30G working shock without derating, and can withstand 50G non working shock. It weighs 7.88 grams and has passed UL, CE, C-TICK, and CSA certifications.
1785-CHBM
专业销售世界各大电气品牌产品产品海外直接采购，正品库存，价格优惠售后保修，型号齐全，一样的产品，不一样的价格与服务。大量供应原装进口DCS系统配件，PLC系统配件。主营:ABB、GE发那科、Bentl本特利、Triconex英维思、Woodward伍德沃德、Foxboro福克斯波罗、Westinghouse西屋/Emerson艾默生、Reliance瑞恩、SchneiderModicon施耐德莫迪康、A-B、HIMA黑马、Motorola摩托罗拉、Kollmorgen科尔摩根Bosch/Rexroth/博世力上乐，NI,YOKOGAWA横河，等各大品牌的DCS系统配件，机器人系统配件，大型伺服系统停产备件。
1785-CHBM
