3500/22M瞬时数据接口(TDI)是接口3500监控系统之间兼容软件(系统1状态监控和诊断软件和3500系统配置软件)。TDI结合了3500/20框架接口模块的功能(RIM)具有通信的数据收集能力处理器,如TDXnet。 TDI位于与电源相邻的插槽中3500架。它与M系列显示器(3500/40M, 3500/42M等。)连续收集稳态和瞬态动态(波形)数据并传递该数据通过以太网链接到主机软件。请参考兼容性部分了解更多信息信息。静态数据采集能力是TDI的标准配置。但是,使用可选的通道启用磁盘将允许TDI捕捉动态和高分辨率瞬态数据也是。TDI整合 了通信3500框架内的处理器功能。尽管TDI提供了某些与整个机架，它不是关键监控路径的一部分，并且对整体的正常运行没有影响自动机械保护监控系统。每-3500机架需要一个TD或RIM, 它总是占用插槽1 (在电源旁边)。
3500-22M
3500-22M
The 3500/22M Transient Data Interface (TDI) is compatible software between 3500 monitoring systems (System 1 Status Monitoring and Diagnostic Software and 3500 System Configuration Software). The TDI combines the functionality of the 3500/20 Framework Interface Module (RIM) with a data collection capability processor for communication, such as TDXnet. TDI is located in 3500 slots adjacent to the power supply. It continuously collects steady-state and transient dynamic (waveform) data with M-series displays (3500/40M, 3500/42M, etc.) and transmits this data to the host software through Ethernet connection. Please refer to the compatibility section for more information. The static data collection capability is a standard configuration of TDI. However, using optional channel enabled disks will allow TDI to capture dynamic and high-resolution transient data as well. TDI integrates the processor functions within the communication 3500 framework. Although TDI provides some coverage for the entire rack, it is not a part of the critical monitoring path and does not affect the overall normal operation of the automatic mechanical protection monitoring system. Each -3500 rack requires a TD or RIM, which always occupies slot 1 (next to the power supply).
3500-22M
3500-22M
