5136- DNP-PCI是由Reliance电气公司生产的DEVICENET接口模块33 MHz 32位PCI总线。5136-DNP-PCI有二 十个集成电路和三个微控制器。卡上有两组跳线插针。5136 DNP PCI有一个单晶体振荡器。前面板上有一个薄荷绿的方形电容器，还有一个淡蓝色的固定线性电阻器。然后，电路板被十多个多层芯片陶瓷电容和六十五个表面贴装电阻(也称为SMD)覆盖。该电路板还具有超过45个小型表面贴装元件,标有字母”Z ”,代表杂项，因此它们可能是更多的电阻或电容。5136 DNP PCI的左侧有一块薄金属板。在这块薄金属板上，有一个灰色的标准母端子。母标准端子板有五个开口，每个开口.上方有一个螺钉。每个开口都有颜色编码。顶部开口为色，第二个开口为浅蓝色，第三个开口为浅灰色，第四个开口为色,第五个也是最后一个开为红色。有关5136-DNP-PCI功能的更多信息，请参阅RelianceElectric的多用户手册和数据表。
5136-DNP-PCI
5136- DNP-PCI is a 33 MHz 32-bit PCI bus produced by Reliance Electric Company, which connects to the C module of the DVICENET. 5136-DNP-PCI has twenty integrated circuits and three microcontrollers. There are two sets of jumper pins on the card. The 5136 DNP PCI has a single crystal oscillator. There is a mint green square capacitor on the front panel and a light blue fixed linear resistor. Then, the circuit board is covered by more than ten multi-layer chip ceramic capacitors and sixty-five surface mount resistors (also known as SMDs). The circuit board also has over 45 small surface mount components, Marked with letters Z “represents miscellaneous items, so they may be more resistors or capacitors. There is a thin metal plate on the left side of the 5136 DNP PCI. On this thin metal plate, there is a gray standard female terminal. The female standard terminal board has five openings, each with a screw above it. Each opening is color coded. The top opening is colored, the second opening is light blue, the third opening is light gray, the fourth opening is colored, and the fifth opening is also colored The last one is turned red. For more information on the 5136-DNP-PCI feature, please refer to RelianceElectric’s multi user manual and data sheet.
5136-DNP-PCI
专业销售世界各大电气品牌产品产品海外直接采购，正品库存，价格优惠售后保修，型号齐全，一样的产品，不一样的价格与服务。大量供应原装进口DCS系统配件，PLC系统配件。主营:ABB、GE发那科、Bentl本特利、Triconex英维思、Woodward伍德沃德、Foxboro福克斯波罗、Westinghouse西屋/Emerson艾默生、Reliance瑞恩、SchneiderModicon施耐德莫迪康、A-B、HIMA黑马、Motorola摩托罗拉、Kollmorgen科尔摩根Bosch/Rexroth/博世力上乐，NI,YOKOGAWA横河，等各大品牌的DCS系统配件，机器人系统配件，大型伺服系统停产备件。
5136-DNP-PCI
