每个数字输出模块执行特定类型的输出投票器诊断(OVD)每一点。此安全功能允许在各种多重故障下不受限制地操作TRICONEX 9563-810案。通常，在OVD执行期间，每个点的命令状态是暂时的在一个输出驱动器上一个接一个地反转。 模块上的环回允许每个TRICONEX 9563-810微处理器读取该点的输出值，以确定是否存在潜在故障在输出电路内。(对于不能容忍任何长度的信 号转换的设备，0VD在交流和直流电压下，数字输出模块都可以禁用。
TRICONEX 9563-810交流数字输出模块在交流电压数字输出模块上,由0VD过程识别的故障开关导致输出信号转换到相反状态，最多半个交流周期。这转换可能并非对所有现场设备都是透明的。检测到故障后,模块停止0VD的进-步迭代。交流电压数字输出模块上的每个点需要定期循环到”开”和”关”状态，以确保100%的故障覆盖率。
9563-810
9563-810
Each digital output module performs a specific type of output voter diagnosis (OVD) at each point. This safety feature allows unrestricted operation of the TRICONEX 9563-810 case under various multiple faults. Usually, during OVD execution, the command state of each point is temporarily reversed one after another on an output driver. The loopback on the module allows each TRICONEX 9563-810 microprocessor to read the output value of that point to determine if there is a potential fault in the output circuit. For devices that cannot tolerate signal conversion of any length, the digital output module of 0VD can be disabled under both AC and DC voltages.
The TRICONEX 9563-810 AC digital output module has a fault switch identified by the 0VD process on the AC voltage digital output module, causing the output signal to transition to the opposite state for up to half an AC cycle. This conversion may not be transparent to all on-site devices. After detecting a fault, the module stops the further iteration of 0VD. Each point on the AC voltage digital output module needs to be periodically cycled to the “on” and “off” states to ensure 100% fault coverage.
9563-810
9563-810
