3500/1 5交流电源模块和直流电源模块为半高模块必须安装在机架左侧的指定槽位上。的3500机架可以包含-个或两个电源的任何组合交流和直流。任何一种电源都可以为整个机架供电。当机架内安装两个电源时，下方的电源插槽充当主电源， 耐-个在上插槽充当备份供应。如果安装，第二个电源是备份主要的一一个。拔插任何一个电源模块都不停机机架只要安装第二电源即可正常运行。 3500/15交流和直流电源接受广泛的输入电压，并将其转换为可接受的电压,以供他人使用3500模块。描述该选项使用通用AC电源和通用交流电源输入模块(PIM)。输入电压1 10至220伏标称85至264伏rms120至373 Vac pk通用交流电源和电源输入模块没有兼容传统的高电压交流或低电压交流单元。
127610-01
127610-01
1. 3500/15交流和直流电源OK LED
2.旧的低压直流电源输入模块
3.传统高压直流电源输入模块
4.传统高压交流电源输入模块
5.旧低压交流电源输入模块
6.通用交流电压电源输入模块
7.高压直流电源输入模块
8.低压直流电源输入模块
127610-01
127610-01
The 3500/15 AC power module and DC power module are half height modules that must be installed in the designated slot on the left side of the rack. The 3500 rack can contain any combination of one or two power supplies, AC and DC. Any type of power supply can power the entire rack. When two power supplies are installed in the rack, the lower power slot serves as the main power supply, and the upper slot serves as the backup supply. If installed, the second power supply is the backup primary one. Inserting or unplugging any power module does not shut down the rack. As long as a second power supply is installed, it can operate normally. The 3500/15 AC and DC power supplies accept a wide range of input voltages and convert them into acceptable voltages for others to use with the 3500 module. Describe the use of a universal AC power supply and a universal AC power input module (PIM) for this option. The input voltage 1 10 to 220 volts is standardized as 85 to 264 volts, rms 120 to 373 Vac pk. The universal AC power supply and power input module are not compatible with traditional high-voltage AC or low-voltage AC units.
127610-01
