3500 TDI(暂态数据接口)是3500之间的接口监控系统和GE的system 1*机械管理软件。的TDI结合了3,500 /20机架接口模块(RIM)的能力数据收集能力的通信处理器，如TDXnet。 TDI与M系列- 起在3500机架的RIM插槽中运行监视器(3500/40M, 3500/42M等)连续采集稳态和暂态波形数据，并将该数据通过以太网链路传递给主机软件(请参阅本文档末尾的兼容性部分。)静态数据捕获是TDI的标准配置,但是使用一个可选的通道启用磁盘将允许TDI捕获动态或瞬态数据。的与以前的通信相比，TDI在几个方面进行了改进并将通信处理器功能集成到3500架。尽管TDI提供了整个机架通用的某些功能，但它并不是部分关键监控路径,对正常、正常无影响整个监控系统的运行。每3500机架需要一个TDI或RIM，它总是占用槽位1(电源旁边)。对于三模冗余(TMR)应用，3500系统需 要一个TMR版本的TDI。 除了所有标准TDI功能外，TMR TDI还执行“监视器通道比较”。3500tmr配置 使用监控器选项中指定的设置执行监控器投票。使用在这种方法中，TMR TDI不断地比较三(3)的输出。多余的监视。如果TDI检测到来自其中-一个的信息监视器不再等同于其他监视器(在配置的百分比内)两个监视器，它将监视器标记为错误，并将事件放置在系统事件列表。
138607-01
138607-01
3500 TDI (Transient Data Interface) is the interface monitoring system between 3500 and GE’s system 1 * mechanical management software. The TDI combines the capabilities of the 3500/20 Rack Interface Module (RIM) with data collection capabilities of communication processors such as TDXnet. The TDI and M series operate monitors (3500/40M, 3500/42M, etc.) in the RIM slot of the 3500 rack to continuously collect steady-state and transient waveform data, and transmit this data to the host software through an Ethernet link (see compatibility section at the end of this document). Static data capture is a standard configuration for TDI, but using an optional channel to enable the disk will allow TDI to capture dynamic or transient data. Compared to previous communication, TDI has made improvements in several aspects and integrated communication processor functions into 3500 racks. Although TDI provides certain functions that are common to the entire rack, it is not a critical monitoring path and does not affect the operation of the entire monitoring system. Each 3500 rack requires one TDI or RIM, which always occupies slot 1 (next to the power supply). For the third mock examination Redundancy (TMR) applications, the 3500 system requires a TMR version of TDI. In addition to all standard TDI functions, TMR TDI also performs “monitor channel comparison”. The 3500tmr configuration uses the settings specified in the monitor options to perform monitor voting. In this method, TMR TDI continuously compares three (3) outputs. Redundant monitoring. If TDI detects that the information monitor from one of them is no longer equivalent to the other monitors (within the configured percentage), it marks the monitor as an error and places the event in the system event list.
