3500/22M框架接口模块是连接3500框架的基本接口。它支持本特利内华达公司专有协议，用作组态框架和收集机器信息。RIM必须安装在框架的槽位(与电源模块紧挨着)。
RIM提供一个连接， 它支持当前本特利内华达通讯处理器(外部瞬态数据接口TDIX和外部动态数据接口DDIX)。
RIM使用两种类型的I/O模块，即框架接口/O模块和数据管理I/O模块。这些I/O模块让你把主计算机和通讯处理器与3500框架连接起来, – -次只能在RIM(盘装或架装框架中)的后面或RIM(壁挂式框架)的上面安装-个框架接口I/O模块。对于3500监测系统，有效的两种框架接口I/O模块是RS -232/RS-422I/O模块和调制解调器I/O模块。以下特性为两种I/O模块共有的。框架接口I/O模块必须安装在框架接口模块的后面(盘装或架装框架)或者在框架接口模块的上面(壁挂式框架)。
288055-01
288055-01
The 3500/22M Rack Interface Module is the basic interface for connecting to the 3500 rack. It supports Bently Nevada proprietary protocols as a configuration framework and collects machine information. The RIM must be installed in the slot of the frame (next to the power module).
RIM provides a connection that supports the current Bentley Nevada communication processor (external transient data interface TDIX and external dynamic data interface DDIX).
RIM uses two types of I/O modules, namely framework interface/O modules and data management I/O modules. These I/O modules allow you to connect the main computer and communication processor to the 3500 rack, and only one rack interface I/O module can be installed at a time behind the RIM (disk mounted or rack mounted frame) or above the RIM (wall mounted frame). For the 3500 monitoring system, the two effective framework interface I/O modules are the RS-232/RS-422 I/O module and the modem I/O module. The following characteristics are common to both I/O modules. The frame interface I/O module must be installed behind the frame interface module (disk or rack mounted frame) or above the frame interface module (wall mounted frame).
288055-01
288055-01
专业销售世界各大电气品牌产品产品海外直接采购，正品库存，价格优惠售后保修，型号齐全，一样的产品，不一样的价格与服务。大量供应原装进口DCS系统配件，PLC系统配件。主营:ABB、GE发那科、Bentl本特利、Triconex英维思、Woodward伍德沃德、Foxboro福克斯波罗、Westinghouse西屋/Emerson艾默生、Reliance瑞恩、SchneiderModicon施耐德莫迪康、A-B、HIMA黑马、Motorola摩托罗拉、Kollmorgen科尔摩根Bosch/Rexroth/博世力上乐，NI,YOKOGAWA横河，等各大品牌的DCS系统配件，机器人系统配件，大型伺服系统停产备件。
288055-01
