3500/22M是由本特利内华达开发的瞬态数据接口模块。它用作与 3500 监测系统兼容的软件接口（系统 1 状态监测和诊断软件以及 3500 系统配置软件）。TDI 将 3500/20 机架接口模块 （RIM功能） 与通信处理器（如 TDXnet）相结合，以收集数据。
3500/22M 功能
- 在 3500 机架中，TDI 位于电源旁边的插槽中。为了持续收集稳态和瞬态动态（波形）数据，并通过以太网链路将这些数据传输到主机软件，它与M系列监视器（3500/40M，3500/42M等）进行交互。
- TDI 具有传统的静态数据收集功能。但是，TDI 也可以使用可选的通道启用磁盘记录动态、高分辨率瞬态数据。
功能说明
- 3500机架容纳了TDI的通信处理功能。尽管TDI执行一些由整个机架共享的任务，但它不是监控系统的关键组件，并且与整个系统监控自主机械保护的程度无关。
- 每个 3500 机架需要一个 TDI 或 RIM，并且始终占用插槽 1。（在电源旁边）。
- 3500 监测系统和兼容软件之间的链路称为 3500/22M 瞬态数据接口 （TDI）（系统 1 状态监测和诊断软件以及 3500 系统配置软件）。TDI 将 3500/20 机架接口模块 （RIM功能） 与通信处理器（如 TDXnet）相结合，以收集数据。
350022M
350022M
The 3500/22M is a transient data interface module developed by Bentley Nevada. It is used as a software interface compatible with the 3500 monitoring system (System 1 status monitoring and diagnostic software, as well as the 3500 system configuration software). TDI combines the 3500/20 Rack Interface Module (RIM function) with communication processors such as TDXnet to collect data.
3500/22M Function
In a 3500 rack, the TDI is located in the slot next to the power supply. In order to continuously collect steady-state and transient dynamic (waveform) data and transmit it to the host software through an Ethernet link, it interacts with M-series monitors (3500/40M, 3500/42M, etc.).
TDI has traditional static data collection capabilities. However, TDI can also use optional channels to enable disk recording of dynamic, high-resolution transient data.
Function Description
The 3500 rack accommodates the communication processing functions of TDI. Although TDI performs tasks shared by the entire rack, it is not a critical component of the monitoring system and is independent of the degree to which the entire system monitors autonomous mechanical protection.
Each 3500 rack requires one TDI or RIM and always occupies slot 1. (next to the power supply).
The link between the 3500 monitoring system and compatible software is called the 3500/22M Transient Data Interface (TDI) (System 1 Status Monitoring and Diagnostic Software and 3500 System Configuration Software). TDI combines the 3500/20 Rack Interface Module (RIM function) with communication processors such as TDXnet to collect data.
