3500/42M是由本特利内华达公司开发的近似地震监测器组件。这是一款四通道监视器，具有接近和地震传感器输入。它将调理信号与用户可编程的报警进行比较，并对信号进行调理以产生振动和位置读数。3500 机架配置软件可用于对每个通道进行编程，以监控和报告径向振动、推力位置、REBAM、加速度、差分膨胀、偏心率、速度和其他参数。
3500/42M 功能
- 监控通道成对设置，最多可以同时执行两个指定的功能。例如，通道 1 和 2 可以执行一个功能，而通道 3 和 4 执行另一个或相同的功能。
- 近端地震监测器通过将监测的参数与选定的报警设定点实时进行比较，触发报警来保护机械。它向操作和维护人员通报关键的机器信息。
- 根据排列方式，每个通道通常会调节其输入信号以产生一组静态值。可以为任何当前静态值建立警报设定值，并为其中任何两个值建立危险设定值。
- 使用机架配置软件为监视器测量的任何值设置警报级别，并为监视器测量的任意两个值设置危险设定值。对于每个测量值，警报可以设置为满量程的 0% 到 100%。当满量程范围超过传感器的范围时，设定值会受到传感器范围的限制。
3500/42M
3500/42M
The 3500/42M is an approximate seismic monitor component developed by Bentley Nevada. This is a four channel monitor with proximity and seismic sensor inputs. It compares the conditioning signal with user programmable alarms and adjusts the signal to generate vibration and position readings. The 3500 rack configuration software can be used to program each channel to monitor and report radial vibration, thrust position, REBAM, acceleration, differential expansion, eccentricity, speed, and other parameters.
3500/42M Function
The monitoring channels are set in pairs and can perform up to two specified functions simultaneously. For example, channels 1 and 2 can perform one function, while channels 3 and 4 perform another or the same function.
The near-end seismic monitor protects the machinery by comparing the monitored parameters with the selected alarm set points in real time and triggering an alarm. It informs operation and maintenance personnel of critical machine information.
According to the arrangement, each channel typically adjusts its input signal to generate a set of static values. You can establish alarm setpoints for any current static value and danger setpoints for any two of them.
Use rack configuration software to set alarm levels for any value measured by the monitor, and set danger settings for any two values measured by the monitor. For each measurement value, the alarm can be set to 0% to 100% of full scale. When the full scale range exceeds the range of the sensor, the set value will be limited by the sensor range.
3500/42M
3500/42M
