3500/64M动态压力监测器是一个单槽 ，四通道监测器，从高温接受输入压力传感器,并使用此输入来驱动警报。的监视器每个通道的一个测量变量是带通动态压力。您可以使用3500机架配置软件进行以下操作配置带通角频率与一个附加陷波滤波器。监视器提供一个记录器输出控制系统的应用。主要用途为3500/64M动压监视器是提供以下内容:
连续比对保护机器根据配置的告警监控参数驱动警报的设定值
操作所需的基本机器信息维修人员
3500/64M
3500/64M
每个通道，根据配置,限制其输入信号产生的各种参数称为被测变量 。您可以配置警报和危险设定值每个活跃的测量变量。低和高过滤模式是选项通道。通道1和通道2形成-对,并且通道3和4是另一对。 你可能在每个上选择不同的带通选项通道对的通道。然而，渠道在对内操作必须相同过滤模式。
您可以设置信号处理，以便监视器只提供通道1输入到所有四个频道。这个特性被称为级联模式，在3500中表示为1 >ALL机架配置软件。在“级联模式”中可以选择过滤模式仅用于通道对的选项。一个传感器提供四个不同通道的输入过滤要求。因此，你可以配置四个单独的带通滤波器选项还有四个独立的全尺寸量程，其中一个传感器输入。这两种过滤方式提供的不同过滤的质量。
3500/64M
3500/64M
The 3500/64M Dynamic Pressure Monitor is a single slot, four channel monitor that receives input pressure sensors from high temperatures and uses this input to drive alarms. One measurement variable for each channel of the monitor is bandpass dynamic pressure. You can use the 3500 rack configuration software to configure the bandpass angular frequency and an additional notch filter. The monitor provides an application of a recorder output control system. The main purpose of the 3500/64M dynamic pressure monitor is to provide the following content:
Continuous comparison of protection machines drives alarm settings based on configured alarm monitoring parameters
The basic machine information required for operation, maintenance personnel, and various parameters generated by limiting the input signal of each channel according to configuration, are called the measured variables. You can configure alarm and danger settings for each active measurement variable. The low and high filtering modes are option channels. Channel 1 and channel 2 form a pair, and channels 3 and 4 are another pair. You may choose different bandpass option channel pairs on each channel. However, channels must operate in the same filtering mode internally.
You can set up signal processing so that the monitor only provides channel 1 input to all four channels. This feature is called cascading mode and is represented in 3500 as 1>ALL rack configuration software. In the “Cascading Mode”, you can choose the option of filtering mode only for channel pairs. A sensor provides input filtering requirements for four different channels. Therefore, you can configure four separate bandpass filter options and four independent full-scale ranges, including one sensor input. These two filtering methods provide different filtering qualities.
3500/64M
