CSI 6500机器状态监控对应于完全符合API 670并为保护和关键、旋转监测机器。特殊技能该系统的数据集成中的保护功能过程自动化DeltaV只有三个简单的鼓掌步骤，瞬态分析现场演示、录制、，暂停和播放， 以及优秀的PeakVue用于早 期检测的处理滚动轴承损坏和驱动的配置装配托架:
-19“装配托架仅适用于保护功能为6-U版本以及标准3HE版本。
-19 “装配托架仅适用于6U中的预测功能安装高度前部或后部传感器接线板。此外,还有一个7.5英寸紧凑型可用的安装宽度。
-用于组合保护功能和预测仅19 “/6 HE使用了装配托架。
完整机器监控功能API 670顺从的
n机柜安装用标准19 “/6 HE模块托架
n系统设计确保在卡出现故障时超过两个频道受到影响待更换
n内部时钟与系统主时钟同步
n冗余ModBus连接，TCP或串行，用于集成第三方控制系统中的保护监视器。预测参数的附加ModBus输出
n个插槽，用于16或32个跳闸继电器输出
n双通道速度
n 12插槽3 U双通道振动或位置监测模块，共24个输入
n前后4- 20mA输出和缓冲信号输出背面
n外部锁定报警输出并提高限值可为每个通道配置
n外部电源，无需插槽数据表
A6410
A6410
CSI 6500 machine status monitoring corresponds to fully compliant API 670 and serves as a protective and critical, rotating monitoring machine. Special skills: The protection function in the data integration of the system, process automation, and DeltaV only have three simple applauding steps: transient analysis, on-site demonstration, recording, pause, and playback, as well as excellent PeakVue for early detection and handling of rolling bearing damage and drive configuration assembly bracket:
-The 19 “mounting bracket is only suitable for the 6-U version with protection function and the standard 3HE version.
-The 19 “mounting bracket is only suitable for predicting the installation height of the front or rear sensor wiring board in the 6U. In addition, there is a 7.5 inch compact available installation width.
-Only 19 “/6 HE uses assembly brackets for combination protection functions and prediction.
Full machine monitoring function API 670 compliant
Standard 19 “/6 HE module bracket for cabinet installation
The system design ensures that in the event of card failure, more than two channels are affected and need to be replaced
Synchronize internal clock with system master clock
Redundant ModBus connection, TCP or serial, used to integrate protection monitors in third-party control systems. Additional ModBus output for predicted parameters
N slots for 16 or 32 trip relay outputs
N Dual channel speed
12 slots 3 U dual channel vibration or position monitoring module with a total of 24 inputs
Front and rear 4-20mA output and buffered signal output back
External locking alarm output and increasing limit values can be configured for each channel
N External power supply, no slot data sheet required
A6410
A6410
