A6500-UM通用测量卡是AMS 6500 ATG机械保护系统的一个组成部分。该卡配备了2个传感器输入通道(独立或组合,根据所选的测量模式)，可与最常见的传感器一起工作, 如涡流、压电(加速度计或速度计)、地震(电动力)、LF(低频轴承振动)、霍尔效应和LVDT(与A6500-LC结合)传感器。 除此之外，该卡包含5个数字输入和6个数字输出。测量信号通过内部rs485总线传输到A6500-CC Com卡,并转换为Modbus RTU和Modbus TCP/ IP协议，进一步传输到主机或分析系统。 此外,Com卡通过面板上的USB插座提供通信，用于连接PC/笔记本电脑进行卡的配置和测量结果的可视化。除此之外，测量结果可以通过模拟输出0/4 -20 mA输出。这些输出有一个共地， 并粗与系统电源电隔离。A6500-UM通用测量卡的操作在A6500-SR系统机架中完成，并提供电源电压和信号的连接。A6500-UM通用测量具有以下功能:
Q轴绝对振动
Q轴相对振动
Q轴偏心率
Q壳体压电振动
推力和杆位置，差速器和外壳膨胀，阀门位置
Q速度和键
A6500-UM
A6500-UM
The A6500-UM universal measurement card is a component of the AMS 6500 ATG mechanical protection system. The card is equipped with 2 sensor input channels (independent or combined, depending on the selected measurement mode) and can work with the most common sensors, such as eddy current, piezoelectric (accelerometer or velocimeter), seismic (electrodynamic), LF (low-frequency bearing vibration), Hall effect, and LVDT (combined with A6500-LC) sensors. In addition, the card contains 5 digital inputs and 6 digital outputs. The measurement signal is transmitted to the A6500-CC Com card through the internal RS485 bus and converted into Modbus RTU and Modbus TCP/IP protocols, which are further transmitted to the host or analysis system. In addition, the Com card provides communication through a USB socket on the panel for connecting PC/laptop computers for card configuration and visualization of measurement results. In addition, the measurement results can be output through analog outputs of 0/4-20 mA. These outputs have a common ground and are electrically isolated from the system power supply. The operation of the A6500-UM universal measurement card is completed in the A6500-SR system rack and provides power supply voltage and signal connections. A6500-UM universal measurement has the following functions:
Q-axis absolute vibration
Relative vibration of Q-axis
Q-axis eccentricity
Q shell piezoelectric vibration
Thrust and rod position, differential and casing expansion, valve position
Q speed and keys
A6500-UM
A6500-UM
